Запчасти Doosan Daewoo EMERGENCY STEERING BODY PARTS

-

400-00566

EMERGENCY STEERING PIPING

SC: D

-2шт.

1

401-00129A

EMERG. STEER PUMP-DC MOTOR

desc: POMPE

1шт.

2

S0512263

BOLT M10X1.5X30

desc: BOULON A 6 PANS

4шт.

3

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

4

DS2018057

HOSE 850L

desc: TUYAU FLEXIBLE

1шт.

5

DS2059412

HOSE 2000L

desc: TUYAU FLEXIBLE

1шт.

6

2184-1036D386

HOSE 750L

desc: TUYAU FLEXIBLE

1шт.

7

S8000241

O-RING

desc: JOINT TORIQUE

2шт.

8

2181-2566D4

ADAPTER

desc: RACCORD

1шт.

9

S8030121

O-RING

desc: JOINT TORIQUE

2шт.

10

2181-2627D1

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

11

2181-2289D4

TEE

desc: TE

1шт.

12

420-00128

VALVE;CHECK

desc: VANNE

1шт.

13

2549-1135D4

SWITCH;PRESSURE 10bar

SERIAL: 2001-2043

1шт.

13

2549-1135D11

SWITCH;PRESSURE 3bar

SERIAL: 2044

1шт.

14

S8180221

SEAL;RING

desc: RONDELLE D'ETANCHEITE

1шт.

15

2181-1920D4

ADAPTER PT1/2-PF1/2

desc: RACCORD

1шт.

16

S8000181

O-RING

desc: JOINT TORIQUE

1шт.

17

2181-1126D2

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

18

S8040121

O-RING

desc: JOINT TORIQUE

1шт.

19

2181-1126D3

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

20

2420-1029

VALVE;CHECK

desc: CLAPET DE RETENUE

1шт.

21

2181-1126D22

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

22

S8000291

O-RING

desc: JOINT TORIQUE

1шт.

23

S0515253

BOLT M12X1.75X30

desc: BOULON A 6 PANS

4шт.

24

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.

25

S5010713

WASHER M12

desc: RONDELLE

4шт.

26

195-01484

BRACKET

desc: SUPPORT

1шт.

27

2181-1110D3

ADAPTER PT1/2-PF1/2

desc: RACCORD

1шт.

28

2180-1026D2

O-RING

desc: JOINT TORIQUE

1шт.

29

2181-9079

FLANGE;HALF

desc: BRIDE

2шт.

30

S2212266

BOLT M10X1.5X30

desc: BOULON A 6 PANS CREUX

4шт.

31

S5110603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

32

S8040101

O-RING

desc: JOINT TORIQUE

1шт.

33

2184-1036D165

HOSE PF1/4-1540L

desc: TUYAU FLEXIBLE

1шт.

34

S8000231

O-RING

desc: JOINT TORIQUE

1шт.
