Запчасти Doosan Daewoo REMOTE CONTROL VALVE-2 SPOOL HYDRAULIC PARTS

-

4420-9443A

REMOCON VALVE-2SPOOL

SERIAL: 1001-1010

1шт.

1

21321300

LEVER KIT

desc: KIT DE LEVIER

1шт.

2

25920200

BELLOWS

desc: GAINE DE PROTECTION

1шт.

3

21332400

HANDLE

desc: BARRE

1шт.

4

21331400

BUTTON;PUSH

SC: D

1шт.

5

19873000

NUT;STOP

desc: BAGUE

1шт.

6

21329600

SHIM KIT

desc: KIT DE CALE

1шт.

7

19954400

BRACKET;CARDAN

SC: D

1шт.

8

21318500

JOINT KIT

desc: KIT DE JOINT

1шт.

9

23623719

SLEEVE;CENTERING

SC: D

2шт.

10

19952600

JOINT

desc: JOINT

1шт.

11

25867900

FLANGE

SC: D

1шт.

12

39815800

SOLENOID

desc: SOLENOIDE

1шт.

13

25868000

BRACKET;ELECTRIC

SC: D

1шт.

14

21318700

PROTECT PUSH KIT

desc: KIT DE PROTEGER POUSSER

4шт.

15

21333400

PLUNGER KIT

desc: PLUNGEUR

4шт.

16

21317600

REGULATING SUB ASS'Y

desc: SOUS-ENSEMBLE REGLEMENT

4шт.

17

21319700

SPRING;RETURN

desc: RESSORT

4шт.

18

21319100

PREFEELING POINT KIT

desc: PRESENTIR POINTE

4шт.

19

21319800

PLUG KIT

desc: BOUCHON

1шт.

20

21319200

CONTROL PORT KIT

desc: KIT DE AUTORITE PORT

1шт.

21

-

BODY

SC: D

1шт.
