Запчасти Doosan Daewoo AIRCONDITIONER(2) BODY PARTS

-

920-00030

COOLER & HEATER ASS'Y

SC: D

-2шт.

21

2520-6004

CONDESER ASS'Y

desc: ENSEMBLE COMPRESSEUR

1шт.

21A

2520-6005

CORE ASS'Y;CONDENSER

desc: . ENSEMBLE COMPRESSEUR

1шт.

21B

2538-6018

FAN MOTOR ASS'Y

desc: . MOTEUR

1шт.

21C

2520-6006

NET;CONDENSER

desc: . ENSEMBLE COMPRESSEUR

1шт.

22

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

6шт.

23

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

6шт.

24

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

6шт.

25

195-00140

BRACKET;CONDENSER

desc: SUPPORT

1шт.

26

195-01170A

BRACKET;CONDENSER

desc: SUPPORT

1шт.

27

S0558553

BOLT M10X1.5X50

desc: BOULON A 6 PANS

4шт.

28

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

29

2114-1058D1

WASHER

desc: RONDELLE M10

5шт.

30

2512-1077

RUBBER;CUSHION

desc: CAOUTCHOUC

8шт.

31

2185-1697D1

HOSE;LIQUID(1) 610L

desc: TUYAU FLEXIBLE

1шт.

31A

2180-6090

O-RING

desc: . JOINT TORIQUE

2шт.

32

4185-1775D4

HOSE;LIQUID(2) 2100L

desc: TUYAU FLEXIBLE

1шт.

32A

2180-6090

O-RING

desc: . JOINT TORIQUE

2шт.

33

2204-6039A

RECEIVER;DRIER

desc: RESERVOIR DESSICATEUR

1шт.

34

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

2шт.

35

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

37

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

6шт.

38

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.

39

2114-1058D29

WASHER

desc: RONDELLE

6шт.

40

2185-1308D7

HOSE 4000L

desc: TUYAU FLEXIBLE

1шт.

41

2185-1308D8

HOSE 4300L

desc: TUYAU FLEXIBLE

1шт.

42

2186-9005

COCK

desc: ROBINET

1шт.

43

S8450016

CLAMP;HOSE

desc: COLLIER

4шт.

44

2124-1509D3

CLIP D24/M8

desc: ATTACHE

2шт.

45

2124-1509D6

CLIP D42/M8

desc: ATTACHE

5шт.

46

2121-1305

NUT

desc: ECROU

5шт.

49

2124-1622D3

CLIP;BAND 280L

desc: ATTACHE

10шт.
