Запчасти Doosan Daewoo BRAKE & PILOT SUPPLY VALVE HYDRAULIC PARTS

-

4420-9475A

VALVE;BRAKE & PILOT SUPPLY

SERIAL: 1-102

-2шт.

1

DXP15146

BODY

SC: D

1шт.

2

AXP13541-01

CHECK CART. 3CAX13541-01(C1.C2.C3.C4)

desc: . REPRIMER

4шт.

2A

SK226

KIT;SEAL

desc: .. KIT DE JOINTS D'ETANCHEITE

1шт.

2A-1

-

O-RING(BS013)

SC: K

1шт.

2A-2

-

O-RING(BS115)

SC: K

1шт.

2A-3

-

O-RING(BS113)

SC: K

1шт.

2A-4

-

RING;BACK-UP(MS113)

SC: K

1шт.

3

AXP13509-01

RELIEF CARTRIDGE 1DRX13509-01(C5)

desc: . DECHARGE

1шт.

3A

SK243

KIT;SEAL

desc: .. ADAPTATEUR

1шт.

3A-1

-

O-RING

SC: K

1шт.

3A-2

-

O-RING

SC: K

1шт.

3A-3

AXP3984

RING;BACK-UP

SC: K

1шт.

4

AXP15099-01

CARTRIDGE;SEQ. PRES.1DSX15099-01(C6)

desc: . RACCORD ADAPTATEUR

1шт.

4A

SK177

KIT;SEAL

desc: .. KIT DE JOINTS D'ETANCHEITE

1шт.

4A-1

-

RING;BACK-UP(BS016)

SC: K

1шт.

4A-2

-

O-RING(BS211-90ўЄ)

SC: K

1шт.

4A-3

-

O-RING(BS016-90ўЄ)

SC: K

1шт.

4A-4

-

O-RING(BS118-90ўЄ)

SC: K

1шт.

5

AXP14231-01

CARTRIDGE;RED. PRES. 1PAX14231-01(C7)

desc: . RACCORD ADAPTATEUR

1шт.

5A

SK177

KIT;SEAL

desc: .. KIT DE JOINTS D'ETANCHEITE

1шт.

5A-1

-

O-RING(BS211-90ўЄ)

SC: K

1шт.

5A-2

-

O-RING(BS016-90ўЄ)

SC: K

1шт.

5A-3

-

RING;BACK-UP(BS016)

SC: K

1шт.

5A-4

-

O-RING(BS118-90ўЄ)

SC: K

1шт.

6

AXP12650

SOLENOID CARTRIDGE(C8)

desc: . CARTOUCHE SOLENOIDE

1шт.

7

AXP12651

SOLENOID CARTRIDGE(C9)

desc: . CARTOUCHE SOLENOIDE

1шт.

8

AXP12670

SOLENOID CARTRIDGE(C10)

desc: . CARTOUCHE SOLENOIDE

1шт.

9

AXP9921-04

SOLENOID COIL

desc: . CARTOUCHE SOLENOIDE

2шт.

10

AXP14417

HONED ASSEMBLY

desc: . ENSEMBLE DE HONE

1шт.

10A

AXP12666

PILOT SLEEVE

SC: D

1шт.

10B

AXP14416

PILOT PIN

SC: D

1шт.

11

-

O-RING BS1806;012-90ўЄ(131109)

desc: . RACCORD ADAPTATEUR

1шт.

12

-

RING BACK-UP 012(142012)

desc: . BAGUE DE SOUTIEN

1шт.

13

AXP980

FLOW REG. RETAINER

desc: . BAGUE

1шт.

14

AXP2894

HONED ASSEMBLY

desc: . ENSEMBLE DE HONE

1шт.

14A

AXP1803

SLEEVE

SC: D

1шт.

14B

AXP2895

SPOOL

SC: D

1шт.

15

AXP3922

SPRING

desc: . RESSORT

1шт.

16

-

O-RING BS1806;120-90ўЄ(134120)

desc: . RACCORD ADAPTATEUR

1шт.

17

-

O-RING BS1806;020-90ўЄ(134108)

desc: . RACCORD ADAPTATEUR

1шт.

18

-

O-RING BS1806;019-90ўЄ(134107)

desc: . RACCORD ADAPTATEUR

1шт.

19

-

RING;BACK-UP 020(145020)

desc: . BAGUE DE SOUTIEN

1шт.

20

-

RING;BACK-UP 019(145019)

desc: . BAGUE DE SOUTIEN

1шт.

25

AXP7297

PLUNGER

desc: . PLONGEUR

1шт.

29

AXP9921-06

SOLENOID COIL

desc: . CARTOUCHE SOLENOIDE

1шт.

30

AXP8380

SOLENOID NUT

desc: . CARTOUCHE SOLENOIDE

1шт.
