Запчасти Doosan Daewoo STAND ASSY(3)-OPEN CAB FRONT PARTS

-

195-01022

STAND ASS'Y-OPEN CAB

SC: D

-2шт.

1

4901-9038

SEAT

desc: SIEGE

1шт.

2

4512-1106E

ELECTRIC BOX ASS'Y

desc: ENSEMBLE ELECTRICITE

1шт.

2-1

4512-1134

ELECTRIC BOX

desc: . ENSEMBLE ELECTRICITE

1шт.

2-2

4621-2861B

COVER

desc: . COUVERCLE

1шт.

2-3

4621-2862A

COVER

desc: . COUVERCLE

1шт.

2-4

4621-2863A

COVER

desc: . COUVERCLE

1шт.

2-5

4621-2860B

PLATE

desc: . PLAQUE

1шт.

2-6

4621-2859B

PLATE

desc: . PLAQUE

1шт.

2-7

S0512053

BOLT M10X1.5X25

desc: . BOULON A 6 PANS

6шт.

2-8

S5010613

WASHER;PLAIN M10

desc: . RONDELLE

6шт.

2-9

S5102603

WASHER;SPRING M10

desc: . RONDELLE ELASTIQUE

6шт.

2-10

S0504553

BOLT M6X1.0X14

desc: . BOULON A 6 PANS

9шт.

2-11

S5010313

WASHER;PLAIN M6

desc: . RONDELLE

13шт.

2-12

S5102303

WASHER;SPRING M6

desc: . RONDELLE ELASTIQUE

13шт.

2-13

S3450973

SCREW M6X1.0X16

desc: . VIS

4шт.

2-14

2161-1744

BUSHING;RUBBER

desc: . CAOUTCHOUC

1шт.

15

4191-3439H

FLOOR PLATE

desc: TAPIS DE SOL

1шт.

18

S2208761

BOLT;SOCKET M8X1.25X18

desc: BOULON A 6PANS

4шт.

20

2120-2166D4

BOLT M10X1.5X20

desc: BOULON A 6PANS

8шт.

21

2114-1898D1

WASHER;PLAIN

desc: RONDELLE

8шт.

23

2120-2166d27

BOLT M12X1.75X25

desc: BOULON A 6 PANS

4шт.

24

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

25

2114-1898D9

WASHER;PLAIN

desc: RONDELLE

4шт.

29

2114-1961D3

WASHER;SPRING

desc: RONDELLE ELASTIQUE

8шт.

30

2114-1961D4

WASHER;PLAIN

desc: RONDELLE

8шт.

31

2120-2208D1

BOLT M20x2.5x50

desc: BOULON A 6 PANS

8шт.

32

4621-2900B

COVER

desc: COUVERCLE

1шт.

33

4621-2901C

COVER

desc: COUVERCLE

1шт.
