Запчасти Doosan Daewoo EMERGENCY STEER KIT FRONT PARTS

-

4400-1780

EMERGENCY STEER KIT

desc: KIT DE DIRECTION

-2шт.

1

4401-9187

PUMP KIT;EMER. STEER

desc: POMPE

1шт.

2

4420-9356

VALVE;SWITCH

desc: VANNE

1шт.

3

2181-1950D1

PLUG PFO1/4"

desc: BOUCHON

1шт.

4

2184-1036D182

HOSE PF3/4-1080L

desc: TUYAU FLEXIBLE

1шт.

5

2184-1089D30

HOSE PF1-650L-5000PSI

desc: TUYAU FLEXIBLE

1шт.

6

2184-1089D31

HOSE PF1-400L-5000PSI

desc: TUYAU FLEXIBLE

1шт.

7

2184-1026D382

HOSE PF3/4-870L

desc: TUYAU FLEXIBLE

1шт.

8

2184-1036D305

HOSE PF3/4-2800L

desc: TUYAU FLEXIBLE

1шт.

9

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

6шт.

10

4621-3977

PLATE

SERIAL: 1-241

1шт.

10

4621-3977A

PLATE

SERIAL: 242

1шт.

11

S0515253

BOLT M12X1.75X30

desc: BOULON A 6 PANS

2шт.

12

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

2шт.

13

S2212061

BOLT;SOCKET M10X1.5X25

desc: BOULON A 6 PANS CREUX

2шт.

14

2181-1126D22

ADAPTER PFO1-PF3/4

desc: RACCORD ADAPTATEUR

1шт.

15

S8000291

O-RING P29

REP_PNO: 8202-023

1шт.

16

2181-1917D44

ADAPTER M22X1.5-PF3/4

desc: RACCORD ADAPTATEUR

1шт.

17

S8180341

PACKING

desc: RONDELLE D'ETANCHEITE

1шт.

18

2181-1917D45

ADAPTER M42X2-PF3/4

SERIAL: 1-241

1шт.

18

4181-2803

ADAPTER M42X2-PF3/4

SERIAL: 242

1шт.

19

S8180631

SEAL RING

SERIAL: 1-205

3шт.

19

S8181631

SEAL RING

SERIAL: 206-241

3шт.

19

S8180631

SEAL RING

SERIAL: 242

3шт.

20

2181-1917D43

ADAPTER M42X2-PF1

SERIAL: 1-241

1шт.

20

4181-2808

ADAPTER M42X2-PF1

SERIAL: 242

20шт.

21

4181-2532

ADAPTER M42X2.0-PF1

SERIAL: 1-241

1шт.

21

4181-2532A

ADAPTER M42X2.0-PF1

SERIAL: 242

1шт.

22

4181-2550

ADAPTER M33X2.0-PF3/4

desc: RACCORD ADAPTATEUR

1шт.

23

S8180521

SEAL RING

desc: BAGUE D'ETANCHEITE

1шт.

24

2181-1126D105

ADAPTER PF3/4

SERIAL: 1-177

1шт.

24

2181-1702D71

ELBOW 2-PF3/4

SERIAL: 178

1шт.

25

S8000111

O-RING P11

REP_PNO: 8202-009

1шт.

26

2181-1917D46

ADAPTER M48X2-PF3/4

SERIAL: 1-241

1шт.

26

4181-2804

ADAPTER M48X2-PF3/4

SERIAL: 242

1шт.

27

S8180691

SEAL RING

SERIAL: 1-205

1шт.

27

S8181691

SEAL RING

SERIAL: 206-241

1шт.

27

S8180691

SEAL RING

SERIAL: 242

1шт.

35

4140-1057

PIPE

desc: CONDUITE

1шт.

36

2181-9078

FLANGE

desc: COLLIER A BRIDE

2шт.

37

2114-1058D10

WASHER;PLAIN

desc: RONDELLE PLATE

2шт.

38

2114-1058D30

WASHER Ґх13.5XҐх36X2.9T

desc: RONDELLE

2шт.

39

2180-1026D19

O-RING SAE 1"

desc: JOINT TORIQUE

2шт.

40

S2212261

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

4шт.

41

S8000241

O-RING P24

desc: JOINT TORIQUE

1шт.
