Запчасти Doosan Daewoo DUMP CUT-OUT ASSY FRONT PARTS

-

4715-4007

DUMP CUT-OUT ASS'Y

desc: SITUATION

-2шт.

1

4195-4499

BRACKET

desc: SUPPORT

1шт.

2

4533-4001

HOUSING

desc: CARTER

1шт.

3

S0504553

BOLT M6X1.0X14

desc: BOULON A 6 PANS

6шт.

4

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

6шт.

5

S0515053

BOLT M12X1.75X25

desc: BOULON A 6 PANS

4шт.

6

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

5шт.

7

S4012733

NUT M12X1.75

desc: ECROU

3шт.

8

4129-4012

SPRING

desc: RESSORT

1шт.

9

4120-4019

BOLT;STUD

desc: GOUJON

1шт.

10

2549-1116

SWITCH;MICRO

desc: COMMUTATEUR MICRO

1шт.

11

4229-4003

COVER

desc: COUVERCLE

1шт.

12

4160-4012

BOOT

desc: GAINE DE PROTECTION

1шт.

13

4424-4001

PLUNGER

desc: PLONGEUR

1шт.

14

4120-4018

BOLT

desc: BOULON A 6 PANS

1шт.

15

S3400633

SCREW M4X0.7X30

desc: VIS

2шт.

16

S5100103

WASHER;SPRING M4

desc: RONDELLE ELASTIQUE

2шт.

17

S4012103

NUT M4X0.7

desc: ECROU

2шт.

18

4129-4011

SPRING

desc: RESSORT

1шт.
