Запчасти Doosan Daewoo CONTROL STAND-WITHOUT CABIN FRONT PARTS

-

4197-1907

CONTROL STAND ASS'Y

SERIAL: 1-227

1шт.

-

4197-1907A

CONTROL STAND ASS'Y

SERIAL: 228

1шт.

3

4195-3983C

SUPPORT ASS'Y

SC: D

1шт.

3-7

2161-1744

RUBBER;TRIM

desc: . CAOUTCHOUC

1шт.

3-12

4197-1610

BRACKET

desc: . SUPPORT

1шт.

3-13

S0508953

BOLT M8X1.25X22

desc: . BOULON A 6 PANS

4шт.

3-14

S5102503

WASHER;SPRING M8

desc: . RONDELLE ELASTIQUE

4шт.

3-15

S5010513

WASHER;PLAIN M8

desc: . RONDELLE PLATE

4шт.

4

4621-3942

CONTROL STAND

desc: CONSOLE

1шт.

6

4891-1492

TAPE

desc: RUBAN

1шт.

7

4621-2889B

COVER;SWITCH

desc: COUVERCLE

1шт.

8

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

4шт.

9

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

4шт.

14

S3458963

SCREW M6X1.0X14

desc: VIS

8шт.

15

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

4шт.

18

S5010313

WASHER;PLAIN M6

desc: RONDELLE PLATE

8шт.

19

S3458583

SCREW M4X0.7X12

desc: VIS

4шт.

20

S5000113

WASHER;PLAIN M4

desc: RONDELLE PLATE

4шт.

22

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

29

S0504853

BOLT M6X1.0X20

desc: BOULON A 6 PANS

4шт.

34

4621-2918B

PLATE

desc: PLAQUE

1шт.
