Запчасти Doosan Daewoo ENGINE TIMING ENGINE PARTS

1

65.04401-0010

SHAFT;CAM

desc: ARBRE A CAMES

1шт.

2

65.98112-0038

FLANGE

desc: BRIDE

1шт.

3

65.90001-6003

BOLT;HEX. M6X14

desc: BOULON 6 PANS

2шт.

4

65.04501-0057

GEAR;CAM SHAFT

desc: PIGNON D'ARBRE A CAMES

1шт.

5

06.22022-1014

PIN;DOWEL 8M6X28

desc: BROCHE

1шт.

6

06.01913-3119

BOLT;HEX. M8X40

desc: BOULON A 6 PANS

4шт.

8

65.04506-0007

PIN;IDLE GEAR

desc: GOUPILLE DE PIGNON FOU

1шт.

9

65.04505-5009

IDLE GEAR ASS'Y

desc: PIGNON

1шт.

10

65.04507-0003

BUSH;IDLE GEAR

desc: . COUSSINET

1шт.

11

65.04505-0006

GEAR;IDLE

desc: . PIGNON

1шт.

12

65.90720-0018

WASHER;THRUST

desc: RONDELLE DE BUTEE

1шт.

14

06.01914-3225

BOLT;HEX. M10X70

desc: BOULON A 6 PANS

2шт.

15

65.04101-0044

VALVE;EXHAUST

desc: VANNE

6шт.

16

65.04101-0043

VALVE;INTAKE

desc: SOUPAPE D'ADMISSION

6шт.

17

65.04102-6004

SPRING VALVE ASS'Y

desc: RESSORT

6шт.

17-1

65.04102-0002

SPRING;VALVE. INNER

desc: . RESSORT DE INTERIEUR SOUPAPE

6шт.

18

65.04102-0066

SPRING;VALVE. OUTER

desc: . RESSORT DE EXTERIEUR SOUPAPE

6шт.

18-1

65.04102-0066

SPRING;VALVE. OUTER

desc: RESSORT DE EXTERIEUR SOUPAPE

6шт.

19

65.04103-0014

RETAINER;VALVE SPRING

desc: COUPELLE DE RESSORT DE SOUPAPE

12шт.

20

65.04104-0007

COTTER;VALVE

desc: CLAVETTE DE SOUPAPE

24шт.

20-1

65.04200-6017

BOCKER ARM SHAFT ASS'Y

ICA: Y

2шт.

20-1

65.04200-6027A

BOCKER ARM SHAFT ASS'Y

SERIAL: 9700001

2шт.

21

65.04203-5010

ROCKER ARM SHAFT ASS'Y

desc: . ENSEMBLE AXE DE CULBUTEUR

2шт.

22

65.97601-0104

SPRING;ROCKER ARM SHAFT

desc: . RESSORT D'AXE DE CULBUTEURS

4шт.

23

65.04201-5014

ROCKER ARM ASS'Y

desc: . ENSEMBLE AXE DE CULBUTEURS

12шт.

23

65.04201-0007J

ARM;ROCKER

SC: D

12шт.

23

65.93020-0033D

BUSH

SC: D

12шт.

24

65.04205-0003

BOLT;ADJUSTING M10X1.0

desc: . VIS

12шт.

25

65.90501-0003

NUT;HEX. M10X1.0

desc: . ECROU

12шт.

26

65.04202-0011

BRACKET;ROCKER ARM SHAFT

ICA: Y

6шт.

26

65.04202-0014

BRACKET;ROCKER ARM SHAFT

SERIAL: 9700001

6шт.

27

06.15010-2311

WASHER;PLAIN 8.4

desc: RONDELLE

12шт.

28

06.01013-9221

BOLT;HEX. M10X80

desc: BOULON A 6 PANS

12шт.

29

65.97601-0053

SPRING;CONICAL

desc: RESSORT CONIQUE

4шт.

30

65.90710-0039

WASHER;ROCKER ARM

desc: RONDELLE D'AXE DE CULBUTEURS

16шт.

31

06.29010-0120

RING;SNAP 24X1.2

desc: BAGUE

4шт.

32

65.04301-0006

TAPPET;VALVE

desc: POUSSOIR DE TIGE DE CULBUTEUR

12шт.

33

65.04302-5011

ROD;PUSH

desc: TIGE DE POUSSOIR

12шт.

34

65.04902-0010

SEAL;VALVE STEM

desc: JOINT DE QUEUE DE SOUPAPE

12шт.

35

65.04103-0011

SEAT;VALVE SPRING

desc: SIEGE DE RESSORT DE SOUPAPE

12шт.

36

06.15010-2311

WASHER;PLAIN

desc: RONDELLE PLATE

6шт.

37

06.01283-7112

BOLT;HEX. M8X18

desc: BOULON A 6 PANS

6шт.
