Запчасти Doosan Daewoo CRANK SHAFT ENGINE PARTS

1010

65.02101-7541A

CRANK SHAFT ASS'Y

desc: ENSEMBLE VILEBREQUIN

1шт.

1020

65.02101-7054A

CRANK SHAFT ASS'Y

desc: . ENSEMBLE VILEBREQUIN

1шт.

1030

65.02101-0054

SHAFT;CRANK

SC: D

1шт.

1050

65.02110-0013E

WEIGHT;BALANCE

SC: D

4шт.

1070

65.02110-0014E

WEIGHT;BALANCE

SC: D

4шт.

1090

65.90430-0012B

BOLT;CRANK SHAFT

SC: D

8шт.

1100

65.90430-0013B

BOLT;CRANK SHAFT

SC: D

8шт.

1110

65.02101-0057

CRANK SHAFT

desc: . VILEBREQUIN

1шт.

1120

65.02101-0060

CRANK SHAFT

desc: . VILEBREQUIN

1шт.

1130

65.02115-0008B

GEAR;CRANK SHAFT

desc: PIGNON

1шт.

1150

06.22022-0912

PIN;DOWEL 6M6X20

desc: GOUPILLE D'AJUSTAGE

1шт.

2010

65.02201-7032

DAMPER;VIBRATION

desc: AMORTISSEUR DE VIBRATIONS

1шт.

2040

06.01913-3215

HEX. BOLT ASS'Y M10X25

desc: BOULON 6 PANS

6шт.

3010

65.02301-5015

FLYWHEEL ASS'Y

desc: ENSEMBLE VOLANT

1шт.

3020

65.02301-0180A

FLYWHEEL

desc: . CARTER DE VOLANT MOTEUR

1шт.

3030

65.02310-0011B

GEAR;RING

desc: . COURONNE DENTEE

1шт.

3050

06.22022-1010

PIN;DOWEL 8X16

desc: GOUPILLE DE BLOCAGE 8x16

1шт.

3060

65.90001-0084

BOLT;HEX. M14X1.5X40

desc: BOULON 6 PANS M14x1.5x40

8шт.

3070

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

8шт.

4010

65.02401-6012D

CON-ROD ASS'Y

SERIAL: 000718

6шт.

4010

65.02401-6012E

CON-ROD ASS'Y

SERIAL: 000719

6шт.

4020

65.02401-0045E

CONNECTING ROD

SC: D

1шт.

4040

65.90020-0010E

BOLT;CON-ROD

desc: . BOULON A 6 PANS

2шт.

4050

65.02405-1006

BUSH;CON-ROD

SC: B

1шт.

4060

65.91301-0010

PIN;DOWEL

desc: . GOUPILLE D'AJUSTAGE

2шт.

4070

65.02410-6106

METAL;CONNECTION ROD

desc: PALIER

6шт.

4070

65.02410-6107

METAL;BIG END 0.25

SC: US

6шт.

4070

65.02410-6108

METAL;BIG END 0.50

SC: US

6шт.

4070

65.02410-6109

METAL;BIG END 0.75

SC: US

6шт.

5010

65.02501-0778A

PISTON

desc: PISTON

6шт.

5020

65.02503-0057

RING;TOP

desc: SEGMENT COUP DE FEU

6шт.

5030

65.02503-0097

RING;SECOND

desc: SEGMENT DE COMPRESSION

6шт.

5040

65.02503-0105

RING;OIL

desc: SEGMENT RACLEUR

6шт.

5050

65.02502-0050

PIN;PISTON

desc: AXE DE PISTON

6шт.

5060

06.29020-0127

RING;SNAP 45X1.75

desc: CIRCLIP

12шт.

6010

65.02601-0180

PULLEY;V-BELT

desc: POULLIE

1шт.

6020

65.90720-0022

WASHER

SERIAL: 010601

1шт.

6020

REP_PNO: 06.02106-0622

-1шт.

6020

65.90720-0088

WASHER

SERIAL: 010602

1шт.

6030

06.02106-0623

BOLT;SOCKET HEAD

SERIAL: 010601

8шт.

6030

06.02106-0622

BOLT;SOCKET HEAD

SERIAL: 010602

8шт.
