Запчасти Doosan Daewoo BEARING CASE ENGINE PARTS

-

65.11301-7005

INJECTION PUMP DRIVE GEAR ASS'Y

desc: TUYAUTERIE D'INJECTION

1шт.

1

65.11309-0004

CASE;INJECTION PUMP BEARING

desc: CARTER

1шт.

2

65.11301-0009

GEAR;INJECTION PUMP DRIVE

desc: PIGNON D'ENTRAINEMENT DE POMPE D'INJECTION

1шт.

3

65.11308-0001

SHIM 0.1mm

desc: CALE

1шт.

3

65.11308-0002

SHIM 0.15mm

SC: R

1шт.

3

65.11308-0003

SHIM 0.2mm

SC: R

1шт.

3

65.11308-0004

SHIM 0.5mm

SC: R

1шт.

4

65.11312-0007

COVER;INJECTION PUMP BEARING CASE

desc: COUVERCLE DE CARTER-PALIER DE POPME

1шт.

6

06.01913-3116

BOLT;HEX. M8X28

desc: BOULON A 6 PANS

3шт.

7

06.29141-0215

KEY;WOODRUFF 6X22

desc: CLAVETTE WOODRUFF

2шт.

8

65.90501-0022

NUT;HEX. M24X1.5

desc: ECROU

1шт.

9

06.16050-0316

WASHER;LOCK

desc: RONDELLE D'ARRET

1шт.

10

65.11302-0006

SHAFT;INJECTION PUMP DRIVE

desc: ARBRE D'ENTRAINEMENT DE POMPE D'INJECTION

1шт.

11

06.32092-0307

BEARING;TAPER ROLLER

desc: ROULEMENT A ROULEAUX CONIQUES

2шт.

12

65.01510-0151

SEAL;OIL A32X52X9

desc: JOINT D'HUILE

1шт.

13

06.22022-0912

PIN;DOWEL 6M6X20

desc: GOUPILLE D'AJUSTAGE

2шт.

14

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

1шт.

15

06.01914-3225

BOLT ASS'Y M10X70

desc: BOULON A 6 PANS

2шт.

16

06.06225-0809

BOLT;STUD M10X35

desc: GOUJON

1шт.

17

06.11063-8215

MUTT;HEX. M10X1.5

desc: ECROU

1шт.

18

06.16044-0211

WASHER;SPRING B10

desc: RONDELLE ELASTIQUE

2шт.

19

06.01013-9213

BOLT;HEX. M10X40

desc: BOULON A 6 PANS

2шт.

20

65.11902-0016

GASKET

desc: JOINT

1шт.
