Запчасти Doosan Daewoo TIMING GEAR CASE ENGINE PARTS

1

65.01903-0027

GASKET;TIMING GEAR CASE

desc: JOINT

1шт.

2

65.01304-0004G

CASE;TIMING GEAR

desc: CARTER DE DISTRIBUTION

1шт.

3

06.01914-3215

BOLT;HEX. M10X25

desc: BOULON A 6 PANS

2шт.

5

65.01943-3317

BOLT;HEX. M12X1.5X30

desc: BOULON A 6 PANS

6шт.

7

06.01493-4309

BOLT;HEX. M12X1.5X50

desc: BOULON A 6 PANS

2шт.

8

06.16731-2109

WASHER;SPRING A12

desc: RONDELLE ELASTIQUE

2шт.

9

06.11063-9216

NUT;HEX. M12X1.5

desc: ECROU

1шт.

10

06.16731-2109

WASHER;SPRING A12

desc: RONDELLE ELASTIQUE

1шт.

11

06.22022-0712

PIN;DOWEL 4M6X20

desc: GOUPILLE D'AJUSTAGE

1шт.

14

65.01903-0176

GASKET;TIMING GEAR CASE COVER

desc: JOINT

1шт.

15

65.01305-5032B

TIMING GEAR CASE COVER ASS'Y

desc: ENSEMBLE COUVERCLE DE CARTER DE

1шт.

16

06.22022-0907

PIN;DOWEL 6M6X12

desc: GOUPILLE D'AJUSTAGE

2шт.

17

65.90720-0003

WASHER M6.4

desc: RONDELLE PLATE

2шт.

18

06.16731-2105

WASHER;SPRING A6

desc: RONDELLE ELASTIQUE

2шт.

19

06.01923-2914

BOLT;HEX. M6X22

desc: BOULON A 6 PANS

17шт.

19-1

06.01283-6917

BOLT;HEX. M6X30

desc: BOULON A 6 PANS

2шт.

20

65.01510-0026

SEAL;CRANK SHAFT(FRONT)-EXPORT

desc: BAGUE D'ETANCHEITE VILEBREQUIN(AVANT)

1шт.

21

65.01813-5009

OIL PIPE ASS'Y

desc: TUYAU

1шт.

22

65.01810-5003

CAP;OIL FILLER

desc: BOUCHON DE REMPLISSAGE D'HUILE

1шт.

23

65.01908-0004

GASKET

desc: JOINT

1шт.

24

06.01283-6913

BOLT;HEX. M6X20

desc: BOULON A 6 PANS

5шт.

25

06.16731-2105

WASHER;SPRING A6

desc: RONDELLE ELASTIQUE

5шт.
