Запчасти Doosan Daewoo INJECTION PIPE ENGINE PARTS

-

65.10301-6035A

PIPE KIT(65.10301-6035A)

desc: CONDUITE

1шт.

1-1

65.10301-6153

INJECTION PIPE ASS'Y

desc: ENSEMBLE CONDUITES D'INJECTION

1шт.

1

65.10301-5173

INJECTION PIPE. CYLINDER NO.1

SC: D

1шт.

2

65.10301-5174

INJECTION PIPE. CYLINDER NO.2

SC: D

1шт.

3

65.10301-5175

INJECTION PIPE. CYLINDER NO.3

SC: D

1шт.

4-1

65.10301-6154

INJECTION PIPE ASS'Y

desc: ENSEMBLE CONDUITES D'INJECTION

1шт.

4

65.10301-5176

INJECTION PIPE. CYLINDER NO.4

SC: D

1шт.

5

65.10301-5177

INJECTION PIPE. CYLINDER NO.5

SC: D

1шт.

6

65.10301-5178

INJECTION PIPE. CYLINDER NO.6

SC: D

1шт.

13

65.96330-0134

TUBE;FUEL OVER FLOW

desc: TUYAU

1шт.

14

65.97445-0001

CLAMP;SPRING

desc: COLLIER A RESSSORT

1шт.

15

65.12301-5096

FUEL OVER FLOW PIPE ASS'Y

desc: ENSEMBLE CONDUITES DE TROP-PLEIN

6шт.

16

65.98150-0042

SCREW;HOLLOW M8X1

desc: VIS CREUSE

6шт.

17

06.56180-0712

RING;SEAL A7X14

desc: BAGUE D'ETANCHEITE

12шт.

18

65.97401-6002

3 PIPE CLIP ASS'Y

desc: ENSEMBLE CLIP 3 TUBES

4шт.

19

65.97401-6001

2 PIPE CLIP ASS'Y

desc: ENSEMBLE CLIP 2 TUBES

2шт.
