Запчасти Doosan Daewoo STEERING PIPING BODY PARTS

-

4400-1709

STEERING PIPING ASS'Y

SERIAL: 1-253

-2шт.

1

4420-9199

VALVE;CUSHION M200

desc: VANNE

1шт.

2

S0508753

BOLT M8X1.25X18

desc: BOULON A 6 PANS

2шт.

3

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

8шт.

4

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

5

S0515053

BOLT M12X1.75X25

SERIAL: 211

4шт.

7

2180-1026D26

O-RING 7/16UNF

desc: JOINT TORIQUE

2шт.

8

2184-1071D9

HOSE PF1/2-630

desc: TUYAU FLEXIBLE

1шт.

9

2184-1061D235

HOSE PF1/4-700

desc: TUYAU FLEXIBLE

2шт.

10

2181-1126D6

ADAPTER PF1/2-PF1/2

desc: RACCORD

6шт.

11

S8000181

O-RING P18

REP_PNO: 8202-014

8шт.

12

4183-4615A

PIPE

desc: TUYAU

2шт.

13

4124-4042

CLAMP;PIPE

desc: ATTACHE DE TUYAU

2шт.

14

S0558253

BOLT M10X1.5X35

desc: BOULON A 6 PANS

4шт.

15

2181-1702D2

ELBOW;S PF1/2

desc: COUDE

2шт.

16

2184-1054D51

HOSE PF1/2-700L

desc: TUYAU FLEXIBLE

1шт.

17

4195-4526A

BRACKET

SERIAL: 1-210

1шт.

17

4195-4526B

BRACKET

SERIAL: 211

1шт.

18

S0715053

BOLT M12X1.25X25

SERIAL: 1-210

4шт.

19

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.

20

2181-1702D42

ELBOW;S PF3/4-PF1/2

desc: RACCORD

2шт.

21

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

4шт.

22

4237-1077

BLOCK;PORT(R.H.)

desc: BLOC

1шт.

24

S8000241

O-RING P24

desc: JOINT TORIQUE

2шт.

27

4195-3242A

BRACKET

SERIAL: 1-210

1шт.

27

4195-3242B

BRACKET

SERIAL: 211

1шт.

28

2184-1071D38

HOSE L580

desc: TUYAU FLEXIBLE

1шт.

29

2184-1054D52

HOSE PF1/2-650L

desc: TUYAU FLEXIBLE

1шт.

30

4237-1078

BLOCK(L.H.)

desc: BLOC

1шт.

31

2181-1702D47

ELBOW PF1/4. UNF7/16

desc: RACCORD

2шт.
