Запчасти Doosan Daewoo ENGINE MOUNTING BODY PARTS

-

201-00055

ENGINE & TRANSMISSION ASS'Y

SC: D

-2шт.

1

201-00075

ENGINE ASS'Y-D1146T

desc: MOTEUR

1шт.

2

210-00005

TRANSMISSION ASS'Y

desc: TRANSMISSION

1шт.

3

181-00446A

ADAPTER;FLANGE

desc: BRIDE

1шт.

4

195-00810A

BRACKET(R.H)

desc: SUPPORT

1шт.

5

195-00809A

BRACKET(L.H)

desc: SUPPORT

1шт.

6

195-00821

BRACKET(R.H)

desc: SUPPORT

1шт.

7

195-00808

BRACKET(L.H)

desc: SUPPORT

1шт.

8

2204-9013E

AIR CLEANER

desc: FILTRE A AIR

1шт.

8A

2474-6003

ELEMENT;OUTER

desc: . ELEMENT

1шт.

8B

2474-6025

ELEMENT;INNER

desc: . ELEMENT

1шт.

9

203-00078

MUFFLER

desc: CILENCIEUX

1шт.

10

161-00104

MOUNT;T/M

desc: CAOUTCHOUC

4шт.

11

4161-9067

MOUNT;E/G

desc: CAOUTCHOUC

4шт.

12

2114-1929

WASHER;REBOUND

desc: RONDELLE PLATE

4шт.

13

4114-4116

WASHER;HARD

desc: RONDELLE

4шт.

14

S4033133

NUT M20X1.5

desc: ECROU

4шт.

15

S0771261

BOLT M20X1.5X120

desc: BOULON A 6PANS

4шт.

16

2204-9032A

PRE CLEANER

desc: PRE-FILTRE A AIR

1шт.

17

2204-9015A

PIPE;EXTENSION

desc: RALLONGE

1шт.

18

2182-4003B

PIPE

desc: TUYAU

1шт.

19

4185-1655B

HOSE;AIR-CLEANER

desc: TUYAU FLEXIBLE

1шт.

20

4185-1679

HOSE;AIR-CLEARER

desc: TUYAU FLEXIBLE

1шт.

21

S8450105

CLAMP;HOSE

desc: COLLIER

2шт.

22

S8450066

CLAMP;HOSE

desc: COLLIER

1шт.

23

S8450127

CLAMP;HOSE

desc: COLLIER

1шт.

24

2170-9005

INDICATOR

desc: INDICATEUR

1шт.

25

2181-2690

ADAPTER

desc: ADAPTEUR

1шт.

26

4180-1143A

GASKET

desc: JOINT

2шт.

27

4182-1604A

PIPE;EXHAUST

desc: CONDUITE

1шт.

28

4124-9026

CLAMP;SEAL

desc: COLLIER

2шт.

29

4193-9003

TUBE;FLEXIBLE

SERIAL: 1001-1198

1шт.

29

4193-9003A

TUBE;FLEXIBLE

SERIAL: 1199

1шт.

30

4910-9003

CAP;RAIN

desc: CHAPEAU DE PALIER

1шт.

31

2124-1076A

BAND;AIR CLEANER

desc: COLLIER FILTRE A AIR

2шт.

32

182-00087

PIPE;FILLER

desc: CONDUITE

1шт.

33

4187-9002

DIPSTICK

desc: JAUGE D'HUILE

1шт.

34

S0527461

BOLT M20X2.5X40

SERIAL: 1001-1021

8шт.

34

S0527561

BOLT M20X2.5X45

SERIAL: 1022

8шт.

35

S5103101

WASHER;SPRING M20

desc: RONDELLE ELASTIQUE

8шт.

36

S0518253

BOLT M14X2.0X30

desc: BOULON A 6PANS

1шт.

37

S5102803

WASHER;SPRING M14

desc: RONDELLE ELASTIQUE

5шт.

38

S2212266

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6PANS

8шт.

39

S5110603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

12шт.

40

S0558153

BOLT M10X1.5X30

desc: BOULON A 6PANS

12шт.

41

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

22шт.

42

S2212866

BOLT;SOCKET M10X1.5X60

desc: BOULON A 6PANS

4шт.

43

S4032833

NUT M14X1.5

desc: ECROU

4шт.

44

S0511953

BOLT M10X1.5X22

desc: BOULON A 6PANS

4шт.

45

S4012633

NUT M10X1.5

desc: ECROU

6шт.

46

S2209666

BOLT;SOCKET M8X1.25X50

desc: BOULON A 6PANS

2шт.

47

S5110503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

48

S0718461

BOLT M14X1.5X40

desc: BOULON A 6PANS

4шт.

49

S0560453

BOLT M12X1.75X35

desc: BOULON A 6PANS

8шт.

50

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

8шт.

51

2120-2166D1

BOLT M10X1.5X30

desc: BOULON A 6PANS

8шт.

52

2114-1898D1

WASHER M10

desc: RONDELLE

8шт.
