Запчасти Doosan Daewoo ENGINE CONTROL ASSY BODY PARTS

-

201-00077

ENGINE CONTROL

SC: D

-2шт.

1

4134-9401

PEDAL ASS'Y

SERIAL: 1001-1133

1шт.

1

134-00028

PEDAL ASS'Y

SERIAL: 1134

1шт.

2

S5010313

WASHER;PLAIN M6

desc: RONDELLE

3шт.

3

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

6шт.

4

S0504853

BOLT M6X1.0X20

desc: BOULON A 6PANS

3шт.

5

4139-6062

CABLE;CONTROL 2350L

desc: CABLE DE COMMANDE

1шт.

6

2523-9016

MOTOR;ENGINE STOP

desc: MOTEUR

1шт.

7

S0508453

BOLT M8X1.25X12

desc: BOULON A 6PANS

1шт.

8

S5010513

WASHER;PLAIN M8

desc: RONDELLE M8

2шт.

9

S0508853

BOLT M8X1.25X20

desc: BOULON A 6PANS

2шт.

10

4197-1586A

BRACKET

desc: SUPPORT

1шт.

11

S0504553

BOLT M6X1.0X14

desc: BOULON A 6PANS

3шт.

12

2195-3468A

BRACKET

desc: SUPPORT

1шт.

13

4197-1585

LEVER

desc: LEVIER

1шт.

14

S0512053

BOLT M10X1.5X25

desc: BOULON A 6PANS

2шт.

15

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

16

2138-9006B

BALL;JOINT

desc: ENSEMBLE DE JOINT

1шт.

17

S4012233

NUT M5X0.8

desc: ECROU

1шт.

18

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE

1шт.

19

S0556253

BOLT M8X1.25X45

SERIAL: 1001-1184

1шт.

19

S0509853

BOLT M8X1.25X60

SERIAL: 1185

1шт.

20

2124-1353D2

CLIP

desc: CLIP

1шт.

21

S0512053

BOLT M10X1.5X25

desc: BOULON A 6PANS

2шт.
