Запчасти Doosan Daewoo OIL PAN ENGINE PARTS

10

65.05801-5230

PAN;OIL

SERIAL: 051223

1шт.

10

65.05801-5248

PAN;OIL

SERIAL: 051224

1шт.

30

06.56190-0732

RING;SEAL A30X36

desc: JOINT

1шт.

40

06.01913-3119

BOLT ASS'Y M8X40

SERIAL: 051223

32шт.

40

06.01913-3119

BOLT ASS'Y M8X40

SERIAL: 051224

23шт.

50

65.05904A0002

GASKET;OIL PAN

desc: JOINT

1шт.

60

65.96340-6012

DRAIN HOSE ASS'Y

desc: BAGUE

1шт.

70

65.96340-5057

HOSE;DRAIN

desc: . TUYAU FLEXIBLE

1шт.

80

65.98130-0203

ADAPTER

desc: . JAUGE D'HUILE

1шт.

90

65.98125-5004A

COCK;DRAIN

desc: . TUBE DE GUIDAGE

1шт.

100

65.05805-5221

GAUGE;OIL LEVEL

SERIAL: 051117

1шт.

100

65.05805-5221A

GAUGE;OIL LEVEL

SERIAL: 051118

1шт.

110

65.05806-5083C

TUBE;GUIDE

desc: BAGUE

1шт.

120

65.96501-0419

O-RING

desc: . JONT TORIQUE

2шт.

130

65.91701-0208

SPACER

desc: JAUGE D'HUILE

1шт.

140

65.97480-0149

BRACKET

desc: SUPPORT

1шт.

150

06.01283-6913

BOLT;HEX M6X20

desc: BOULON A 6 PANS

1шт.

160

06.11063-8212

NUT;HEX M6

desc: ECROU

1шт.

170

06.16731-2105

WASHER;SPRING

desc: JAUGE D'HUILE

1шт.

180

06.15010-2309

WASHER;PLAIN

desc: RONDELLE

1шт.

190

65.97460-0001

CLIP;BAND

desc: ATTACHE

1шт.
