Запчасти Doosan Daewoo STEERING ASSY BODY PARTS

-

303-00022A

STEERING COLUMN ASS'Y

SERIAL: 4001-4039

-2шт.

-

303-00022B

STEERING COLUMN ASS'Y

SERIAL: 4040

-2шт.

1

303-00023

COLUMN

desc: ENSEMBLE DE DIRECTION

1шт.

2

S0515053

BOLT M12X1.75X25

desc: BOULON

4шт.

3

2114-1898D6

WASHER

desc: RONDELLE

4шт.

4

195-00579C

BRACKET

desc: SUPPORT

1шт.

5

4161-9036

MOUNT;FLEX

desc: SUPPORT

4шт.

6

2120-2166D29

BOLT M10X1.5X40

desc: BOULON

4шт.

7

2114-1898D16

WASHER

desc: RONDELLE

8шт.

8

S0511753

BOLT M10X1.5X18

desc: BOULON

4шт.

9

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

4шт.

10

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

11

621-02962A

COVER

desc: COUVERCLE

1шт.

12

621-02963A

COVER

desc: COUVERCLE

1шт.

13

2120-2166D10

SCREW M6X1.0X14

desc: VIS

8шт.

14

2114-1898D3

WASHER

desc: RONDELLE

8шт.

15

195-02502A

BRACKET

desc: SUPPORT

1шт.

16

S2208866

BOLT;SOCKET M8X1.25X20

desc: BOULON DE PLOT

4шт.

17

S5010503

WASHER;PLAIN

desc: RONDELLE PLATE

4шт.

18

621-02964

COVER

desc: COUVERCLE

1шт.

19

2120-2166D8

SCREW M5X14

desc: VIS

8шт.

20

2114-1898D4

WASHER;PLAIN

desc: RONDELLE PLATE

8шт.

21

4142-1160C

STRIKER

desc: FRAPPER

1шт.

22

S0504353

BOLT M6X1.0X10

desc: BOULON

1шт.

23

4549-6072

SWITCH;SELECTOR(L.H)

desc: INTERRUPTEUR

1шт.

24

4549-9418

SWITCH;COLUMN(R.H)

desc: INTERRUPTEUR

1шт.

25

621-02965

COVER

desc: COUVERCLE

1шт.

26

4197-2434C

BRACKET

desc: SUPPORT

1шт.

27

2114-1898D2

WASHER M8

desc: RONDELLE

2шт.

28

2120-2166D25

BOLT M10X16

desc: BOULON

2шт.

29

154-00012

WHEEL;STEERING

desc: ROUE

1шт.

30

132-00008

KNOB;STEERING WHEEL

desc: BOSSE

1шт.

31

160-00009

CAP;STEERING WHEEL

desc: CHAPEAU

1шт.

32

195-02784B

BRACKET

desc: SUPPORT

2шт.

33

2120-2166D28

BOLT

desc: BOULON

4шт.

34

191-00563B

PLATE

desc: PLAQUE

1шт.

35

K1005190

TRIM;RUBBER

SERIAL: 4040

1шт.
