Запчасти Doosan Daewoo STEERING UNIT HYDRAULIC PARTS

-

420-00523

UNIT;STEERING

desc: UNITE

1шт.

1

2.115-00194

RING;DUST SEAL

SC: K

1шт.

2

-

HOUSING SPOOL & SLEEVE

SC: D

1шт.

3

2.148-00001

BALL Ґх8.5mm

desc: . BILLE

1шт.

4

2.408-00128

BUSHING;THREAD

desc: . BUSH

1шт.

5

2.180-00199

O-RING/ROTO GLYD

SC: K

1шт.

7

2.109-00085

BEARING ASS'Y

desc: . ROULEMENT

1шт.

8

2.115-00080

RING

desc: . ANNEAU

1шт.

9

2.123-00129

PIN;CROSS

desc: . GOUPILLE

1шт.

11

2.405-00086

CARDON SHAFT

desc: . ARBRE

1шт.

12

K9000778

SET OF SPRINGS

desc: . RESSORT

1шт.

13

2.180-00200

O-RING

SC: K

3шт.

14

2.412-00143

DISTRIBUTOR PLATE

desc: . PLAQUE

1шт.

15

K9000779

GEARWHEEL SET

desc: . PIGNON

1шт.

17

2.430-00295

COVER;END

desc: . COUVERCLE

1шт.

18

2.114-00806

WASHER

SC: K

7шт.

20

2.120-00510

SCREW WITH PIN

desc: . VIS

1шт.

21

2.120-00483

SCREW

desc: . VIS

6шт.

*

2.911-00060

SEAL KIT

desc: KIT DE JOINT

1шт.
