Запчасти Doosan Daewoo TIMING GEAR CASE ENGINE PARTS

28
32
29
31
49
60
61
62
30
49
28
36
34
2
27
4
43
1
42
41
12
9
13
43
42
41
44
16
43
42
41
10
25
38
40
39
47
26
5
8
3
6
20
18
21
23
24
19
16
50
22
51
52

Артикул

Название

Примечание

Количество

1

65.01903C0021

GASKET(TIMING GEAR CASE)

desc: GARNITURE

1шт.

2

65.01304-0010N

CASE;TIMING GEAR

desc: CARTER

1шт.

3

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

1шт.

4

06.01913-3113

BOLT;HEX. M8X20

desc: BOULON A 6 PANS

5шт.

5

06.06225-0704

BOLT;STUD M8X20

desc: BOULON DE GOUJON

1шт.

6

06.11063-8214

NUT;HEX. M8

desc: ECROU 6 PANS

1шт.

8

06.01943-3317

BOLT;HEX. M12X1.5X30

desc: BOULON A 6 PANS

4шт.

9

65.90201-0048

BOLT;STUD

desc: BOULON DE GOUJON

1шт.

10

06.06225-0809

BOLT;STUD M10X35

desc: BOULON DE GOUJON

6шт.

12

65.01903B0113

GASKET(TIMING GEAR CASE COVER)

desc: GARNITURE

1шт.

13

65.01305-5028C

TIMING GEAR CASE COVER ASS'Y

desc: COUVERCLE

1шт.

16

06.01923-2914

BOLT;HEX. M6X22

desc: BOULON A 6 PANS

13шт.

18

65.01903B0029

GASKET(TIMING GEAR CASE COVER)

desc: GARNITURE

1шт.

19

65.01307-5009

TIMING GEAR CASE COVER ASS'Y

SERIAL: 051005

1шт.

19

65.01307-5002

TIMING GEAR CASE COVER ASS'Y

SERIAL: 051006

1шт.

20

06.15010-2309

WASHER 6.4

desc: RONDELLE

2шт.

21

06.16731-2105

WASHER;SPRING A6

desc: RONDELLE ELASTIQUE

2шт.

22

06.01923-2918

BOLT;HEX. M6X35

desc: BOULON A 6 PANS

9шт.

23

65.90201-0146

BOLT;STUD M6X16

desc: BOULON DE GOUJON

2шт.

24

06.11063-8212

NUT;HEX. M6

desc: ECROU 6 PANS

2шт.

25

06.22022-0907

PIN;DOWEL 6M6X10

desc: GOUPILLE

2шт.

26

65.01510-0157

SEAL;CRANK SHAFT(FRONT)

desc: JOINT

1шт.

27

65.54903A0013

GASKET

desc: GARNITURE

1шт.

28

65.54302-0006A

BRACKET;AIRCON

SERIAL: 050113

1шт.

28

65.54302-0006B

BRACKET;AIRCON

SERIAL: 050114

1шт.

29

06.02090-0511

BOLT;SOCKET HEAD

desc: BOULON DE PLOT

2шт.

30

06.02090-0513

BOLT;SOCKET HEAD

desc: BOULON DE PLOT

2шт.

31

65.54306-0003

ANGLE;BRACKET

desc: SUPPORT

1шт.

32

06.01913-3215

BOLT;HEX. M10X1.5X25

desc: BOULON A 6 PANS

2шт.

34

65.95840-0033

BRACKET;IDLE PULLEY

desc: SUPPORT

1шт.

36

06.01913-3213

BOLT;HEX. M10X1.5X20

desc: BOULON A 6 PANS

3шт.

38

65.11401-0040

MOUNTING FLANGE ASS'Y

desc: BRIDE

1шт.

39

65.11902-0018A

GASKET

desc: GARNITURE

1шт.

40

06.22220-1110

PIN;SPRING

desc: GOUPILLE

1шт.

41

06.15010-2312

WASHER;PLAIN 10.5

desc: RONDELLE PLATE

11шт.

42

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

11шт.

43

06.11063-8215

NUT;HEX. M10

desc: ECROU 6 PANS

11шт.

44

65.90201-0059

BOLT;STUD M10X35

desc: BOULON DE GOUJON

4шт.

47

65.93410-0036

BEARING;BALL

desc: A BILLES ROULEMENT

1шт.

49

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

4шт.

50

65.27901-0005B

GASKET;END COVER

SERIAL: 051005

1шт.

51

65.91605-0009

COVER;END

SERIAL: 051005

1шт.

52

06.01913-2911

BOLT;HEX. M6X16

SERIAL: 051005

4шт.

60

65.91701-0273

RING;SPACER

desc: ANNEAU D'ENTRETOISE

1шт.

61

65.91701-0088

SPACER

desc: ENTRETOISE

1шт.

62

06.01283-7524

BOLT;HEX. M16X65

desc: BOULON A 6 PANS

1шт.

Выбрано товаров: 46
