Запчасти Doosan Daewoo PISTON ENGINE PARTS
2
3
4
6
1
5
6
11
8
7
12
12
10
9
1
65.02501-0785
PISTON
desc: PISTON
6шт.
2
65.02503-0054
RING;TOP 111X3.5
desc: ANNEAU
6шт.
3
65.02503-0120
RING;SECOND 111X3.5
desc: ANNEAU
6шт.
4
65.02503-0115
RING;OIL 111X4
desc: ANNEAU
6шт.
5
65.02502-0010
PIN;PISTON 42X20X95
desc: GOUPILLE
6шт.
6
06.29020-0126
RING;SNAP 42X1.75
desc: ANNEAU DE SOUTIEN
12шт.
7
65.02401-6101E
CONNECTING ROD ASS'Y
desc: TIGE
6шт.
8
65.02401-0030
ROD;CONNECTING
SC: D
1шт.
9
65.90020-0009D
BOLT;CONNECTING ROD
SC: D
2шт.
10
65.91301-0010
PIN;DOWEL
desc: . GOUPILLE
2шт.
11
65.02405-0015C
BUSH;SMALL END
SC: B
1шт.
12
65.02410-0010
METAL;CONNECTING ROD
desc: METAL
6шт.
12
65.02410-0011
METAL;CONNECTING ROD 0.25
SC: US
6шт.
12
65.02410-0012
METAL;CONNECTING ROD 0.5
SC: US
6шт.
