Запчасти Doosan Daewoo INTERMEDIATE GEAR ENGINE PARTS

1

65.05200-6034

IDLE GEAR ASS'Y

SC: D

1шт.

2

65.05204-0036

GEAR;IDLE

desc: . PIGNON

1шт.

3

06.31420-0314

BEARING;BALL #6006

desc: . A BILLES ROULEMENT

2шт.

4

06.29020-0132

RING;SNAP 55X2

desc: . ANNEAU DE SOUTIEN

2шт.

5

65.05205-0018

PIN;IDLE GEAR

desc: . GOUPILLE

1шт.

6

06.29010-0125

RING;SNAP 30X2

desc: . ANNEAU DE SOUTIEN

1шт.

7

65.90030-0009

BOLT;SOCKET HEAD M10X60

desc: . BOULON DE PLOT

1шт.

8

65.05100-6022

OIL PUMP ASS'Y

desc: POMPE

1шт.

9

65.05201-0037

GEAR;OIL PUMP DRIVE

desc: . POMPE

1шт.

10

65.05102-0014

HOUSING;OIL PUMP

SC: D

1шт.

11

65.05104-5004

GEAR

desc: . PIGNON

1шт.

12

65.05104-5003

GEAR

desc: . PIGNON

1шт.

13

65.05103-5012

OIL PUMP COVER(REAR)

desc: . COUVERCLE

1шт.

14

65.05103-5015

OIL PUMP COVER(FRONT)

desc: . COUVERCLE

1шт.

15

06.22022-0909

PIN

desc: . GOUPILLE

4шт.

16

06.01013-9118

BOLT;HEX. M8X65

desc: . BOULON A 6 PANS

4шт.

17

65.90510-0012

NUT;LOCK

desc: . ECROU

4шт.

18

06.29141-0207

KEY;WOODRUFF 3X13X5

desc: . CLEF

1шт.

19

06.16050-0311

WASHER;LOCK

desc: . RONDELLE

1шт.

20

06.11053-9217

NUT;HEX M14X1.5

desc: . ECROU 6 PANS

1шт.

21

65.05410-0025

PLUNGER;VALVE

SC: D

1шт.

22

65.97601-0110

SPRING;COMPRESSION

SC: D

1шт.

23

65.90310-0104

SCREW;PLUG

SC: D

1шт.

24

06.22022-0907

PIN;DOWEL M6X10

desc: GOUPILLE

2шт.

26

06.01013-9215

BOLT;HEX. M10X50

desc: BOULON A 6 PANS

2шт.

27

65.90801-0018

WASHER;LOCK

desc: RONDELLE

2шт.
