Запчасти Doosan Daewoo INJECTION PUMP ENGINE PARTS

1

65.11101-7299

PUMP;INJECTION

desc: POMPE

1шт.

1A

65.12101-7026

PUMP;FEED

desc: . POMPE

1шт.

1B

65.11125-0009S

PLUNGER

desc: . PLONGEUR

1шт.

1C

131110-8820

VALVE;DELIVERY

desc: . VANNE

1шт.

1D

131424-1520

VALVE;OVERFLOW

desc: . VANNE

1шт.

3

06.78140-2404

SCREW;HOLLOW M14X1.5

desc: VIS

1шт.

4

06.56190-0706

RING;SEAL A14X20

desc: BAGUE D'ETANCHEITE

2шт.

5

65.98101-0008

DOUBLE BANJO UNION ASS'Y

desc: UNION

1шт.

6

06.15010-2312

WASHER 10.5

desc: RONDELLE

5шт.

7

06.01913-3212

BOLT;HEX. M10X18

desc: BOULON A 6 PANS

2шт.

8

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE ELASTIQUE

5шт.

9

06.11063-9215

NUT;HEX. M10X1.25

desc: ECROU 6 PANS

1шт.

10

65.11401-0034A

BRACKET;F.I.P

desc: SUPPORT

1шт.

12

06.01913-3116

BOLT;HEX. M8X28

desc: BOULON A 6 PANS

6шт.

13

65.90710-0015

WASHER;PLAIN

desc: RONDELLE PLATE

6шт.

14

65.11301-0063

GEAR;DRIVE

desc: PIGNON

1шт.

15

65.11106-0008

COUPLING I/P

desc: FIXATION DE POMPE

1шт.

17

06.11063-8215

NUT;HEX. M10

desc: ECROU 6 PANS

4шт.

18

65.05701-5329

HOSE;OIL

desc: TUYAU FLEXIBLE

1шт.

19

65.98130-0029

ADAPTER

desc: ADAPTEUR

1шт.

20

65.98150-0028

SCREW;HOLLOW

desc: VIS

1шт.

21

06.56180-0714

RING;SEAL

desc: BAGUE D'ETANCHEITE

3шт.

25

65.12301-5022

PIPE;FUEL

desc: TUYAU

1шт.
