Запчасти Doosan Daewoo COOLING WATER PUMP ENGINE PARTS

1

65.06500-6145C

WATER PUMP ASS'Y

desc: POMPE

1шт.

5

65.06506-0023

IMPELLAR

desc: . TURBINE

1шт.

6

65.06520-6007

SEAL;MECHANICAL

desc: . JOINT

1шт.

7

65.93410-0027

BEARING;UNIT

desc: . UNITE

1шт.

8

06.29020-0132

RING;SNAP 52X2

desc: . ANNEAU DE SOUTIEN

1шт.

11

65.06504-0030A

HUB

desc: . MOYEU

1шт.

12

65.06501-0076C

HOUSING;WATER PUMP

SC: D

1шт.

13

65.06901A0019

GASKET(WATER PUMP.INNER)

desc: . GARNITURE

1шт.

14

65.06512-0010

COVER;WATER PUMP

desc: . COUVERCLE

1шт.

15

06.04201-8907

BOLT M6X14

desc: . BOULON

3шт.

19

65.06606-0037

PULLEY;V-BELT

desc: POULIE

1шт.

20

65.06611-0109A

FLANGE;FAN

desc: BRIDE

1шт.

21

65.06601-5065

FAN;COOLING

desc: VENTENT

1шт.

22

65.90701-0087

WASHER

desc: RONDELLE

6шт.

23

06.16731-2107

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

24

06.01013-9127

BOLT;HEX

desc: BOULON A 6 PANS

6шт.

26

65.06901A0020

GASKET(WATER PUMP.OUTER)

desc: GARNITURE

1шт.

27

06.01913-3125

BOLT;HEX. M8X70

desc: BOULON A 6 PANS

1шт.

28

06.01913-3126

BOLT;HEX. M8X75

SERIAL: 031211

1шт.

28

06.01013-9121

BOLT;HEX. M8X80

SERIAL: 031212

1шт.

29

06.16731-2107

WASHER

SERIAL: 031212

1шт.

30

06.01913-3121

BOLT;HEX. M8X50

desc: BOULON A 6 PANS

3шт.

31

06.01914-3225

BOLT;HEX. M10X70

desc: BOULON A 6 PANS

1шт.
