COOLING SYSTEM

Запчасти Doosan Daewoo COOLING SYSTEM ENGINE PARTS

22
12
16
35
13
36
10
9
17
18
17
27
19
26
21
27
29
28
21
27
26
27
2
7
1
3
4
8
5
3
4
6
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

65.01705-0002

COVER;WATER CHAMBER

SERIAL: 040909

1шт.

1

65.01705-0002B

COVER;WATER CHAMBER

SERIAL: 040910

1шт.

2

65.01907A0002

GASKET(WATER CHAMBER COVER)

desc: GARNITURE

1шт.

3

06.15010-2311

WASHER 8.4

desc: RONDELLE

12шт.

4

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

12шт.

5

06.01923-3115

BOLT;HEX. M8X25

desc: BOULON A 6 PANS

14шт.

6

65.90201-0037

BOLT;SPACER

desc: BOULON

2шт.

7

65.90201-0149

BOLT;STUD M8X25

desc: BOULON DE GOUJON

1шт.

8

06.11063-8214

NUT;HEX

desc: ECROU 6 PANS

11шт.

9

65.06301-0134B

PIPE;COOLING WATER

desc: TUYAU

1шт.

10

65.06903A0011

GASKET(COOLING WATER PIPE)

desc: GARNITURE

3шт.

12

06.01923-3122

BOLT;HEX. M8X55

desc: BOULON A 6 PANS

3шт.

13

06.01923-3124

BOLT;HEX. M8X65

desc: BOULON A 6 PANS

3шт.

16

66.27435-6008

SWITCH;THERMO

desc: INTERRUPTEUR

1шт.

17

06.67020-0109

CLAMP;HOSE NWS32

desc: FIXATION DE TUYAU

2шт.

18

65.96301-0256

HOSE;RUBBER C/W PIPE

desc: TUYAU FLEXIBLE

1шт.

19

65.06401-6050

THERMOSTAT

desc: THERMOSTAT

1шт.

21

06.67020-0106

CLAMP;HOSE NWS20

desc: FIXATION DE TUYAU

2шт.

22

65.27435-6003

SWITCH;WATER TEMP

desc: INTERRUPTEUR

1шт.

26

04.27405-1908A

HOSE;RUBBER 50X62X80

desc: TUYAU FLEXIBLE

2шт.

27

06.67020-0109

CLAMP;HOSE MWS40

desc: FIXATION DE TUYAU

4шт.

28

65.06301-0083

PIPE;OIL COOLER

desc: TUYAU

1шт.

29

65.96301-0118B

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

35

65.90310-0168

SCREW;PLUG M26X1.5

desc: BOUCHON

1шт.

36

06.56190-0728

RING SEAL A26X32

desc: JOINT

1шт.
