Запчасти Doosan Daewoo OIL TANK BODY PARTS

-

470-00064

OIL TANK ASS'Y

SC: D

-2шт.

1

470-00063H

TANK;OIL

desc: RESERVOIR DE HUILE

1шт.

2

2471-9051B

ELEMENT;FILTER

desc: ELEMENT

1шт.

3

2426-1175

VALVE;BY-PASS

desc: VANNE

1шт.

4

2129-1393

SPRING

desc: RESSORT

1шт.

5

S8012000

O-RING

desc: JOINT TORIQUE

1шт.

6

2473-1080

COVER

desc: COUVERCLE

1шт.

7

S0512053

BOLT M10X1.5X25

desc: BOULON

18шт.

8

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

20шт.

9

193-00568A

PIPE;SUCTION

desc: TUYAU

1шт.

10

S8011200

O-RING

desc: JOINT TORIQUE

2шт.

15

473-00032

COVER

SERIAL: 3001-3008

1шт.

15

473-00032A

COVER

SERIAL: 3009

1шт.

17

422-00028A

BREATHER;AIR

desc: RENIFLARD

1шт.

17A

180-00200

PACKING

desc: . JOINT

1шт.

18

S2202766

BOLT;SOCKET M5X0.8X8

desc: BOULON DE PLOT

6шт.

19

2119-1007

GAUGE;LEVEL

desc: INDICATEUR DE NIVEAU

1шт.

20

S8000291

O-RING

desc: JOINT TORIQUE

1шт.

21

2181-1950D9

PLUG

desc: BOUCHON

1шт.

22

2186-9005

COCK;DRAIN

desc: ROBINET DE PURGE

1шт.

23

S0514653

BOLT M12X1.75X16

desc: BOULON

2шт.

24

S0521256

BOLT M16X2.0X30

desc: BOULON

4шт.

25

2114-1816

WASHER;HARD

desc: RONDELLE

4шт.

26

4114-4159A

SHIM

desc: CALE

4шт.

27

195-01023B

BRACKET;COVER

desc: SUPPORT

1шт.

28

S0511853

BOLT M10X1.5X20

desc: BOULON

2шт.

29

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

2шт.

31

2181-1890D2

PLUG

desc: BOUCHON

4шт.

32

S8000111

O-RING

desc: JOINT TORIQUE

4шт.
