Запчасти Doosan Daewoo ELECTRIC BOX ASSY(2) - ELECTRIC PARTS BODY PARTS

-

500-00062

ELECTRIC BOX ASS'Y

desc: EQUIPMENT ELECTRIQUE

1шт.

2

2543-9015

CONTROLLER;STARTER

desc: CONTROLEUR

1шт.

3

S3450943

SCREW M6X1.0X10

desc: VIS

4шт.

4

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

4шт.

5

2523-9007

CONTROLLER;PREHEAT

desc: CONTROLEUR

1шт.

6

S3450943

SCREW M6X1.0X10

desc: VIS

2шт.

7

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

8

2525-1011

UNIT;BLINKER

desc: UNITE

1шт.

9

S3450943

SCREW M6X1.0X10

desc: VIS

1шт.

10

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

1шт.

11

543-00001

UNIT;CONTROL

desc: UNITE DE COMMANDE

1шт.

12

S3450943

SCREW M6X1.0X10

desc: VIS

4шт.

13

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

4шт.

14

2537-9002

TIMER;WIPER

desc: TEMPORISATEUR

1шт.

15

S3450943

SCREW M6X1.0X10

desc: VIS

4шт.

16

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

4шт.

17

2531-1003

CONVERTER;DC-DC

desc: CONVERTISSEUR

1шт.

18

S3450943

SCREW M6X1.0X10

desc: VIS

4шт.

19

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

4шт.

20

2516-1102A

BUZZER;PILOT

desc: VIBRATOR

1шт.

21

S3450943

SCREW M6X1.0X10

desc: VIS

2шт.

22

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

23

2544-9033

RELAY;HEAD LAMP

desc: RELAIS

1шт.

24

2544-9033

RELAY;REAR WORKING LAMP

desc: RELAIS

1шт.

25

2544-9033

RELAY;ENGINE STOP

desc: RELAIS

1шт.

26

2544-9033

RELAY;WIPER

desc: RELAIS

1шт.

27

2544-9033

RELAY;CONDENSER FAN

desc: RELAIS

1шт.

28

2544-9033

RELAY;RETURN TO DIG

desc: RELAIS

1шт.

29

2544-9033

RELAY;RAISE

desc: RELAIS

1шт.

30

2544-9033

RELAY;HORN

desc: RELAIS

1шт.

31

2544-9033

RELAY;SAFETY START

desc: RELAIS

1шт.

32

2544-9033

RELAY;BACK-UP

desc: RELAIS

1шт.

33

2544-9033

RELAY;COMPRESSOR

desc: RELAIS

1шт.

34

2544-9033

RELAY;STEREO

desc: RELAIS

1шт.

35

2544-9033

RELAY;DISPLAY ILL

desc: RELAIS

1шт.

36

2544-9033

RELAY;ALARM

desc: RELAIS

2шт.

37

S3450823

SCREW M5X0.8X10

desc: VIS

9шт.

38

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE

9шт.

39

2190-2037D6

PLATE;NAME(RELAY)

desc: PLATE;NAME

1шт.

40

2190-2037D36

PLATE;NAME(RELAY)

desc: PLATE;NAME

1шт.

41

2190-2037D42

PLATE;NAME(RELAY)

desc: PLATE;NAME

1шт.

42

2190-2037D49

PLATE;NAME(RELAY)

desc: PLATE;NAME

1шт.

43

543-00019

CONTROLLER;T/MISSION

desc: CONTROLEUR

1шт.

44

S3450853

SCREW

desc: VIS

4шт.

45

S5100203

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

46

S5100213

WASHER;PLAIN

desc: RONDELLE PLATE

4шт.

47

530-00071A

HARNESS;ELECTRIC BOX

desc: HARNAIS

1шт.

48

2124-1509D2

CLIP D18/M8

desc: CLIP

2шт.

49

2124-1509D3

CLIP D24/M8

desc: CLIP

3шт.

50

2124-1509D4

CLIP D30/M8

desc: CLIP

1шт.

51

S0508653

BOLT M8X1.25X16

desc: BOULON

6шт.

52

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.

53

2121-1305

NUT M8X1.25

desc: ECROU

1шт.
