Запчасти Doosan Daewoo AIRCONDITIONER(2) BODY PARTS

-

920-00031

COOLER & HEATER ASS'Y

SERIAL: 1001-3022

-2шт.

-

920-00031A

COOLER & HEATER ASS'Y

SERIAL: 3023

-2шт.

11

185-00076

HOSE;DISCHARGE 2700L

desc: TUYAU FLEXIBLE

1шт.

11A

2180-6088

O-RING(CONDENSER)

desc: . JOINT TORIQUE

1шт.

11B

2180-6089

O-RING(COMPRESSOR)

desc: . JOINT TORIQUE

1шт.

11C

1.161-00018

CAP;CHECK PORT(H)

desc: . CHAPEAU

1шт.

12

185-00077

HOSE;SUCTION 3600L

desc: TUYAU FLEXIBLE

1шт.

12A

2180-6086

O-RING(COMPRESSOR)

desc: . JOINT TORIQUE

1шт.

12B

2180-6087

O-RING(EVAPORATOR)

desc: . JOINT TORIQUE

1шт.

12C

1.161-00019

CAP;CHECK PORT(L)

desc: . CHAPEAU

1шт.

13

2520-6004

CONDENSER ASS'Y

desc: CONDENSATEUR

1шт.

13A

2520-6005

CORE ASS'Y

desc: . NOYAU

1шт.

13B

2538-6018

FAN MOTOR ASS'Y

desc: . MOTEUR

1шт.

13C

2520-6006

NET;CONDENSER

desc: . FILET

1шт.

14

S0512053

BOLT M10X1. 5X25

desc: BOULON

6шт.

15

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

6шт.

16

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

6шт.

17

195-01868

BRACKET;CONDENSER(R.H)

desc: SUPPORT

1шт.

18

195-01870

BRACKET;CONDENSER(L.H)

desc: SUPPORT

1шт.

19

S0558553

BOLT M10X1.5X50

desc: BOULON

4шт.

20

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

21

2114-1058D1

WASHER;PLAIN

desc: RONDELLE PLATE

4шт.

22

2512-1077

RUBBER;CUSHION

desc: CAOUTCHOUC

8шт.

23

2185-1697D4

HOSE;LIQUID(1) 530L

desc: TUYAU FLEXIBLE

1шт.

23A

2180-6090

O-RING

desc: . JOINT TORIQUE

2шт.

24

4185-1775D4

HOSE;LIQUID(2) 2100L

desc: TUYAU FLEXIBLE

1шт.

24A

2180-6090

O-RING

desc: . JOINT TORIQUE

2шт.

25

2204-6039A

RECEIVER DRIER

desc: RESERVOIR DESSICATEUR

1шт.

26

S0508653

BOLT M8X1.25X16

desc: BOULON

2шт.

27

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

28

4920-9050A

UNIT;AIRCON

desc: UNITE D'AIRCON

1шт.

29

S0509053

BOLT M8X1.25X25

desc: BOULON

6шт.

30

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

6шт.

31

2114-1058D29

WASHER

desc: RONDELLE

6шт.

35

2124-1509D3

CLIP D24/M8

desc: CLIP

1шт.

36

2124-1509D6

CLIP D42/M8

desc: CLIP

4шт.

37

2121-1305

NUT M12X1.75

desc: ECROU

3шт.

38

2124-1622D3

CLIP;BAND 280L

desc: CLIP

5шт.
