Запчасти Doosan Daewoo WORK SECTION-BUCKET.OPTION HYDRAULIC PARTS

1

08694-151

WORK SECTION COMPONENTS

SERIAL: 1001-1198

1шт.

1A

08566-010

WORK SECT.HOUSING

SC: D

1шт.

1B

12244-001

4 WAY SPOOL

SC: D

1шт.

1C

10844-001

HR ACTUATOR

desc: RACCORD

1шт.

1C-1

12926001

HR ACTUATOR KIT-K12030

desc: RACCORD

1шт.

1C-1A

10841-001

SPOOL STUD

desc: . BOBINE

1шт.

1C-1B

10834-001

HR BONNET

desc: . CHAPEAU

1шт.

1C-1C

03731-104

SCREW

desc: . VIS

4шт.

1C-1D

09285-004

LOCK WASHER

desc: . RONDELLE DE LOC

4шт.

1C-1E

09000-132

O-RING SEAL

desc: . JOINT PROFILE

1шт.

1D

08684-001

LOAD CHECK PLUG

desc: BOUCHON

1шт.

1D-1

12906001

LOAD CHECK PLUG KIT-K12022

desc: BOUCHON

1шт.

1D-1A

08713-001

PLUG

desc: . BOUCHON

1шт.

1D-1B

08714-001

POPPET

desc: . SOUPAPE SOULEVANTE

1шт.

1D-1C

02796-001

SPRING

desc: . RESSORT

1шт.

1D-1D

02710-001

O-RING SEAL

desc: . JOINT TORIQUE

1шт.

1E

21282-005

RELIEF CARTRIDGE-PR70-NAC

desc: CLAPET DE DECHARGE

2шт.

1E-1

12349001

PLUG SEAL KIT-K12044

desc: KIT D'ETANCHEITE

1шт.

1E-1A

02710-001

O-RING SEAL

desc: . JOINT TORIQUE

1шт.

1E-1B

07028-002

O-RING SEAL

desc: . JOINT TORIQUE

1шт.

1E-1C

12050-001

RING;BACK UP

desc: . BAGUE

1шт.

1F

10845-001

HR ACTUATOR

desc: RACCORD

1шт.

1F-1

12928001

HR ACTUATOR KIT-K12029

desc: RACCORD

1шт.

1F-1A

10834-001

HR BONNET

desc: . CHAPEAU

1шт.

1F-1B

10840-001

STOP COLLAR

desc: . BAGUE

1шт.

1F-1C

10841-001

SPOOL STUD

desc: . BOBINE

1шт.

1F-1D

09000-132

O-RING SEAL

desc: . JOINT PROFILE

1шт.

1F-1E

09285-004

LOCK WASHER

desc: . RONDELLE DE LOC

1шт.

1F-1F

03731-104

SCREW

desc: . VIS

4шт.

1F-1G

10842-001

SPRING(LAGER)

desc: . RESSORT

1шт.

1F-1H

10843-001

SPRING(SMALLER)

desc: . RESSORT

1шт.

1F-1I

10831-001

SPACER

desc: . BAGUE

2шт.
