Запчасти Doosan Daewoo WORK SECTION-BOOM HYDRAULIC PARTS

1

08697-028

BOOM SECTION COMPONENT

SERIAL: 1001-1198

1шт.

1A

08567-004

TANDEM WORK SECTION HOUSING

SC: D

1шт.

1B

22371-001

4 WAY SPOOL

SC: D

1шт.

1C

20367-001

HR ACTUATOR

desc: RACCORD

1шт.

1C-1

12929001

HR ACTUATOR KIT-CK12034

desc: RACCORD

1шт.

1C-1A

10829-001

SPACER

desc: . BAGUE

1шт.

1C-1B

20350-001

SPOOL EXTENDER

desc: . BOBINE

1шт.

1C-1C

20349-001

POSITION SPUD

desc: . BOULON

1шт.

1C-1D

20348-001

SPRING COLLAR

desc: . RESSORT

1шт.

1C-1E

10837-001

HR BONNET

desc: . CHAPEAU

1шт.

1C-1F

09000-132

O-RING SEAL

desc: . JOINT PROFILE

1шт.

1C-1G

21775-001

BONNET SPACER

desc: . CHAPEAU

1шт.

1C-1H

09285-004

LOCK WASHER

desc: . RONDELLE DE LOC

4шт.

1C-1I

03731-107

SCREW

desc: . VIS

4шт.

1C-1J

20280-001

SPRING(LAGER)

desc: . RESSORT

1шт.

1C-1K

20281-001

SPRING(SMALLER)

desc: . RESSORT

1шт.

1C-1L

09000-128

O-RING SEAL

desc: . JOINT PROFILE

1шт.

1D

08684-001

LOAD CHECK PLUG

desc: BOUCHON

1шт.

1D-1

12906001

LOAD CHECK PLUG KIT

desc: BOUCHON

1шт.

1D-1A

08713-001

PLUG

desc: . BOUCHON

1шт.

1D-1B

08714-001

POPPET

desc: . SOUPAPE SOULEVANTE

1шт.

1D-1C

02796-001

SPRING

desc: . RESSORT

1шт.

1D-1D

02710-001

O-RING SEAL

desc: . JOINT TORIQUE

1шт.

1E

21284-004

RELIEF CARTRIDGE-PR70-N

desc: CLAPET DE DECHARGE

1шт.

1E-1

12349001

PLUG SEAL KIT-K12044

desc: KIT D'ETANCHEITE

1шт.

1E-1A

02710-001

O-RING SEAL

desc: . JOINT TORIQUE

1шт.

1E-1B

07028-002

O-RING SEAL

desc: . JOINT TORIQUE

1шт.

1E-1C

12050-001

RING;BACK UP

desc: . BAGUE

1шт.

1F

21498-002

ANTI-CAVITATION CHECK PLUG

desc: BOUCHON

1шт.

1F-1

12912001

ANTI-CAVITATION CHECK PLUG KIT

desc: KIT DE BOUCHON

1шт.

1F-1A

02710-001

O-RING SEAL

desc: . JOINT TORIQUE

1шт.

1F-1B

07028-002

O-RING SEAL

desc: . JOINT TORIQUE

1шт.

1F-1C

12050-001

RING;BACK UP

desc: . BAGUE

1шт.

1G

20526-001

HR ACTUATOR

desc: RACCORD

1шт.

1G-1

12930001

HR ACTUATOR KIT

desc: RACCORD

1шт.

1G-1A

10827-001

SLEEVE

desc: . MANCHON

1шт.

1G-1B

09000-132

O-RING SEAL

desc: . JOINT PROFILE

1шт.

1G-1C

21774-001

BONNET SPACER

desc: . CHAPEAU

1шт.

1G-1D

10829-001

SPACER

desc: . BAGUE

1шт.

1G-1E

20281-001

SPRING(LAGER)

desc: . RESSORT

1шт.

1G-1F

09285-004

LOCK WASHER

desc: . RONDELLE DE LOC

4шт.

1G-1G

03731-110

SCREW

desc: . VIS

4шт.

1G-1H

20348-001

SPRING COLLAR

desc: . RESSORT

1шт.

1G-1I

20349-001

POSITION SPUD

desc: . BOULON

1шт.

1G-1J

09000-128

O-RING SEAL

desc: . JOINT PROFILE

1шт.

1G-1K

10834-001

HR BONNET

desc: . CHAPEAU

1шт.

1G-1L

20280-001

SPRING(SMALLER)

desc: . RESSORT

1шт.

1G-1M

20524-001

HR SPACER

desc: . CHAPEAU

1шт.

1G-1N

20350-001

SPOOL EXTENDER

desc: . BOBINE

1шт.
