Запчасти Doosan Daewoo DEFROSTER FRONT PARTS

-

4920-1097

DEFROSTER

SERIAL: 1107-1230

-

4920-1097A

DEFROSTER

SERIAL: 1231

1

4627-1511

COVER

desc: COUVERCLE

1шт.

2

2920-9035

HEATER

desc: CHAUFFAGE

1шт.

3

2181-2538

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

4

2185-1308D28

HOSE;HEATER 1800L

desc: TUYAU FLEXIBLE

2шт.

5

2185-1308D17

HOSE;HEATER 160L

SERIAL: 1107-1267

2шт.

5

2185-1308D1

HOSE;HEATER 60L

SERIAL: 1268

2шт.

6

M0200

CLAMP;HOSE

desc: COLLIER

4шт.

7

M0300

CLAMP;HOSE

desc: COLLIER

4шт.

8

S3450853

SCREW M5X0.8X16

desc: VIS

2шт.

9

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE M5

2шт.

10

S5000213

WASHER;PLAIN M5

desc: RONDELLE

2шт.

11

2549-1132D7

SWITCH

desc: INTERRUPTEUR

1шт.

12

4190-3485

NAME PLATE

desc: PLAQUE D'IDENTIFICATION

1шт.

13

185-00008

HOSE;PROTECTOR

SERIAL: 1231

2шт.

14

2124-1622D1

CLIP;BAND 150L

desc: ATTACHE

5шт.

15

4530-1762

HARNESS;HEATER

desc: FAISCEAU

1шт.

16

S800140H

TERMINAL

desc: COSSE

1шт.

17

S801140H

TERMINAL

desc: TERMINAL

1шт.

18

2124-1622D1

CLIP;BAND 150L

desc: ATTACHE

5шт.
