Запчасти Doosan Daewoo ELEC.PARTS & TACHOMETER DRIVE ENGINE PARTS

1

65.96801-0123

V-BELT 1500

desc: COURROIE

1шт.

2

65.19102-0044

BRACKET;ALTERNATOR MOUNTING

SERIAL: 000220

1шт.

2

65.19102-0044B

BRACKET;ALTERNATOR MOUNTING

SERIAL: 000221

1шт.

3

06.01913-3318

BOLT;HEX. M12X1.75X35

desc: BOULON A 6 PANS

1шт.

5

06.01914-3215

BOLT;HEX. M10X25

desc: BOULON A 6 PANS

2шт.

7A

65.19103-6006

EYE BOLT ASS'Y

desc: BOULON A 6 PANS

1шт.

7

65.90435-0004C

BOLT;ADJUST

desc: . BOULON A 6 PANS

1шт.

8

65.19107-0001

PIECE;GUIDE

desc: . GUIDE

1шт.

9

65.93020-0055

SPACER

desc: . BAGUE D'ECARTEMENT

1шт.

10

06.11063-9217

NUT;HEX

desc: . ECROU 6 PANS

3шт.

11

06.01494-4409

BOLT;HEX

desc: BOULON A 6 PANS

1шт.

12

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

13

65.26201-7049

STARTER 24VX6.0KW

SERIAL: 001206

1шт.

13

65.26201-7049A

STARTER 24VX6.0KW

SERIAL: 001207

1шт.

14

06.06225-0808

BOLT;STUD M10X30

desc: GOUJON M10x30

3шт.

15

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE

3шт.

16

06.11063-8215

NUT;HEX. M10

desc: ECROU 6 PANS M10

3шт.
