Запчасти Doosan Daewoo STEERING ASSY BODY PARTS

-

4305-1005

STEERING SHAFT ASS'Y

SERIAL: 1001-1305

-

4305-1005A

STEERING SHAFT ASS'Y

SERIAL: 1306-1350

-

4305-1005B

STEERING SHAFT ASS'Y

SERIAL: 1351

1

2154-9002A

WHEEL

desc: VOLANT

1шт.

1A

2301-7004

WHEEL

SC: D

1шт.

1B

2549-7013

BUTTON;HORN

SC: D

1шт.

1C

2130-7001

LOCK;SPRING

SC: D

1шт.

1D

2522-7007

CUP

SC: D

1шт.

1E

2129-7003

SPRING

SC: D

1шт.

2

S4032733

NUT M12X1.25

desc: ECROU

1шт.

3

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE M12

1шт.

4

S0502953

BOLT M5X0.8X12

desc: BOULON A 6 PANS

14шт.

5

4146-4003A

STRIKER

desc: SERRURE

1шт.

6

S3503833

SCREW M6X1X10

desc: VIS

2шт.

7

S6510350

RING;RETAINER

desc: BAGUE DE RETENUE

1шт.

8

4109-9402

BEARING;NEEDLE

desc: ROULEMENT A AIGUILLES

1шт.

9

4112-4011

SHAFT

desc: ARBRE

1шт.

10

4303-1013B

COLUMN

desc: COLONNE

1шт.

11

S6001240

BEARING;BALL

desc: PALIER

1шт.

12

S6510420

RING C TYPE

desc: ROND-TYPE C

1шт.

13

S6500200

RING C TYPE

desc: BAGUE

1шт.

14

4135-9401

U-JOINT ASS'Y

desc: JOINT ASS'Y

1шт.

15

4112-4012

SHAFT

desc: ARBRE

1шт.

16

4414-9406

COUPLING;FIEXIBLE

desc: FIXATION DE POMPE

1шт.

17

S0511953

BOLT;M10X1.5X22

desc: BOULON A 6 PANS

4шт.

18

4161-9036

MOUNT;FLEXIBLE

desc: ENSEMBLE SUPPORT DE MONTAGE

4шт.

19

4195-4498C

BRACKET

desc: SUPPORT

1шт.

20

S5032603

WASHER M10

desc: RONDELLE M10

4шт.

21

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

4шт.

22

4191-3260

PLATE

desc: PLAQUE

2шт.

23

4161-4053

PLATE;RUBBER

desc: PLAQUE CAOUTCHOUC

1шт.

24

4195-4484

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

25

S5011113

WASHER;PLAIN

desc: RONDELLE

2шт.

26

4120-4037A

BOLT

desc: BOULON A 6 PANS

1шт.

27

4191-4325

PLATE

desc: PLAQUE

1шт.

28

S0508453

BOLT M8X1.25X12

desc: BOULON A 6 PANS

1шт.

29

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

1шт.

30

4191-4324A

SEAT;SCREW

SERIAL: 1001-1350

1шт.

31

4133-4074

LEVER ASS'Y

SERIAL: 1001-1350

1шт.

31

133-00102

LEVER ASS'Y

SERIAL: 1351

1шт.

33

4110-4025A

BUSH

desc: COUSSINET

2шт.

34

4114-4066

WASHER

desc: RONDELLE

2шт.

35

4120-4039

BOLT M10X1.25X30

desc: BOULON A 6 PANS

2шт.

36

S4220633

NUT;CASTLE M10X1.25

desc: ECROU

2шт.

37

S5735401

PIN;SNAP 2.5X35

desc: BROCHE

2шт.

38

4549-9418

SWITCH;COLUMN

desc: INTERRUPTEUR

1шт.

39

4160-4018A

GAITER;FLEXIBLE

desc: RACCORD

1шт.

40

4191-4322B

PLATE;COVER

desc: PLAQUE

1шт.

41

4191-4323C

PLATE;COVER

SERIAL: 1001-1305

1шт.

41

4191-4323E

PLATE;COVER

SERIAL: 1306

1шт.

42

2132-1137

GRIP(D131232)

desc: POIGNEE

1шт.

43

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE M5

6шт.

45

S0515053

BOLT M12X1.75X25

desc: BOULON A 6 PANS

4шт.

46

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE M12

4шт.

47

2160-1004D21

BUSHING;RUBBER

desc: MANCHON CAOUTCHOUC

1шт.

49

S0512453

BOLT M10X1.5X40

desc: BOULON A 6 PANS

4шт.

50

0501 209 657

GEAR CHANGE UNIT

SERIAL: 1001-1145

1шт.

50

4549-6071

SWITCH;TRANSMISSION SELETION

SERIAL: 1146-1305

1шт.

50

549-00004

SWITCH;TRANSMISSION SELECTION

SERIAL: 1306

1шт.

51

4191-4346B

PLATE

desc: PLAQUE

1шт.

52

4120-2113

BOLT M6X1.0X37

desc: BOULON A 6 PANS

3шт.

53

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

3шт.

54

S4012333

NUT M6X1.0

desc: ECROU M6X1.0

3шт.

55

4160-1277

BUSHING;RUBBER

desc: MANCHON CAOUTCHOUC

1шт.
