Запчасти Doosan Daewoo COVER ASSY-STEEL BODY PARTS

-

4197-2073F2E

CONTROL STAND ASS'Y

SERIAL: 1146-1167

-

4197-2073F2G

CONTROL STAND ASS'Y

SERIAL: 1168-1305

-

4197-2073F2J

CONTROL STAND ASS'Y

SERIAL: 1306

10

2125-1082

COVER;LOWER

desc: CARTER

1шт.

11

2125-1081

COVER;UPPER

desc: CARTER

1шт.

12

2161-1953

PLATE

desc: PLAQUE

1шт.

13

2124-1084D3

CLIP;BAND

desc: ATTACHE

2шт.

14

S3450963

SCREW M6X1.0X14

desc: VIS

9шт.

15

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.

16

2415-9005

NOZZLE;SPINDLE

desc: INJECTEUR

1шт.

18

S5010313

WASHER M6

desc: RONDELLE

2шт.

30

2158-1017D1

PROTECTOR

desc: TUYAU FLEXIBLE

4шт.

32

S8450044

CLAMP;HOSE

desc: COLLIER

13шт.

52

4415-9006

NOZZLE

SERIAL: 1146-1167

4шт.

52

4415-9006A

NOZZLE;ROUND

SERIAL: 1168

4шт.

53

S3460363

SCREW M3X0.5X14

desc: VIS

28шт.

60

S3640523

SCREW M5X0.8

desc: VIS TARAUDEUSE

4шт.

63

S3644193

SCREW;TAPPING M3X16

desc: VIS TARAUDEUSE

2шт.

65

2158-1017D2

PROTECTOR

desc: TUYAU FLEXIBLE

3шт.

72

4621-3864

PLATE

desc: PLAQUE

1шт.
