Запчасти Doosan Daewoo ENGINE MOUNTING BODY PARTS

-

201-00054

ENGINE & TRANS. ASS'Y

SERIAL: 1001-1010

-2шт.

1

201-00053

ENGINE ASS'Y(DB58TI)

desc: MOTEUR

1шт.

2

210-00004

TRANSMISSION ASS'Y

desc: TRANSMISSION

1шт.

3

181-00464

PLATE;ADAPTER

desc: PLAQUE

1шт.

4

115-00089

ADAPTER;RING

desc: ADAPTEUR

1шт.

5

195-00755A

BRACKET;R.H

desc: SUPPORT

1шт.

6

195-00756

BRACKET;L.H

desc: SUPPORT

1шт.

7

4197-2058A

BRACKET;R.H

desc: SUPPORT

1шт.

8

4197-2059B

BRACKET;L.H

desc: SUPPORT

1шт.

9

161-00104

MOUNT;T/M

desc: SUPPORT

4шт.

10

161-00299

MOUNT;E/G

desc: SUPPORT

4шт.

11

2114-1929

WASHER;REBOUND

desc: RONDELLE PLATE

4шт.

12

4114-4116

WASHER;HARD

desc: RONDELLE

4шт.

13

S4033133

NUT M20X1.5

desc: ECROU

4шт.

14

S0771266

BOLT M20X1.5X120

desc: BOULON A 6PANS

4шт.

19

S0512053

BOLT M10X1.5X25

desc: BOULON A 6PANS

7шт.

20

2114-1917A

SHIM

desc: CALE

12шт.

21

203-00058A

MUFFLER;STD

desc: SILENCIEUX

1шт.

22

2204-2008A

AIR CLEANER

desc: FILTRE A AIR

1шт.

22A

2474-6006B

ELEMENT;OUTER

desc: . ELEMENT

1шт.

22B

2474-9038

ELEMENT;INNER

desc: . ELEMENT

1шт.

23

4114-4085

WASHER

desc: RONDELLE

8шт.

24

4183-4795E

MUFFLER;2nd

desc: SILENCIEUX

1шт.

25

198-00026

RUBBER

desc: CAOUTCHOUC

8шт.

26

S4012633

NUT M10X1.5

desc: ECROU

16шт.

27

193-00656A

PIPE;EXHAUST

desc: CONDUITE

1шт.

28

195-01414

BRACKET

desc: SUPPORT

4шт.

29

S0559053

BOLT M10X1.5X75

desc: BOULON A 6PANS

4шт.

30

S0514953

BOLT M12X1.75X22

desc: BOULON A 6PANS

4шт.

31

4180-4011A

GASKET

desc: JOINT

1шт.

32

2204-9037

PRE-CLEANER

desc: PRE-CLEANER

1шт.

33

S0512263

BOLT M10X1.5X30

desc: BOULON A 6PANS

8шт.

34

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

35шт.

35

182-00032B

PIPE;FILLER

desc: CONDUITE

1шт.

36

4187-9002

DIPSTICK

desc: JAUGE D'HUILE

1шт.

37

S2209666

BOLT;SOCKET M8X1.25X50

desc: BOULON A 6PANS

2шт.

38

S5110503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

39

S0518253

BOLT M14X2.0X30

desc: BOULON A 6PANS

1шт.

40

S5102803

WASHER;SPRING M14

desc: RONDELLE ELASTIQUE

1шт.

41

185-00068

HOSE

desc: TUYAU FLEXIBLE

1шт.

42

185-00067

HOSE

desc: TUYAU FLEXIBLE

1шт.

43

2182-1513

PIPE

desc: CONDUITE

1шт.

44

4124-1662

CLAMP;BAND

desc: COLLIER

2шт.

45

4182-1569B

PIPE;PRE CLEANER

desc: CONDUITE

1шт.

46

S0786253

BOLT M12X1.5X30

desc: BOULON A 6PANS

8шт.

47

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

12шт.

48

S0527466

BOLT M20X2.5X40

desc: BOULON A 6PANS

8шт.

49

S5103103

WASHER;SPRING M20

desc: RONDELLE ELASTIQUE

8шт.

50

2181-2690

ADAPTER;FILLER

desc: ADAPTEUR

1шт.

51

2170-9005

INDICATOR

desc: INDICATEUR

1шт.

52

S0565056

BOLT M16X2X40

desc: BOULON A 6PANS

4шт.

53

S5102903

WASHER;SPRING M16

desc: RONDELLE ELASTIQUE

4шт.

54

S2562556

STUD M10X1.5X45

desc: BOULON A 6PANS

12шт.

55

2114-1058D30

WASHER

desc: RONDELLE

4шт.

56

4180-9159

GASKET

desc: JOINT

1шт.

57

4183-3610

PIPE

desc: CONDUITE

1шт.

60

114-00403

WASHER

desc: RONDELLE PLATE

4шт.

61

4181-9089A

PLUG;OIL

desc: BOUCHON

1шт.

62

S0758253

BOLT M10X1.25X35

desc: BOULON A 6PANS

8шт.

63

114-00404

SPACER

desc: BAGUE D'ECARTEMENT

4шт.

64

2124-1024D14

CLAMP;HOSE

desc: COLLIER

3шт.

65

2124-1024D16

CLAMP;HOSE

desc: COLLIER

1шт.
