Запчасти Doosan Daewoo ELECTRIC PARTS(4)-BATTERY (TIER-II) BODY PARTS

-

500-00184

ELECTRIC PARTS

SERIAL: 1011

-2шт.

1

2506-1104

BATTERY MF100

desc: BATTERIE

2шт.

2

2161-1061

CUSHION

desc: COUSSIN

4шт.

3

2514-1005

HOLDER;BATTERY

desc: SAISIR

2шт.

4

2120-1419

BOLT;STUD M10X1.5X210

desc: BOULON DE PLOT

2шт.

5

S4012633

NUT M10X1.5

desc: ECROU

8шт.

6

2124-1441

CLIP

desc: ATTACHE

4шт.

7

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

4шт.

8

S4540603

NUT;WING M10X1.5

desc: ECROU

4шт.

9

2544-9024

RELAY;BATTERY

desc: RELAIS BATTERIE

1шт.

10

S0509053

BOLT M8X1.25X25

desc: BOULON A 6PANS

2шт.

11

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

12

S5010513

WASHER;PLAIN M8

desc: RONDELLE M8

2шт.

13

2527-9004

BREAKER;CIRCUIT 60A

desc: COUPE-CIRCUIT

1шт.

14

2120-1354

SCREW

desc: VIS

2шт.

15

2527-1023A

FUSIBLE LINK 0.5SQ 27A

desc: FUSIBLE

1шт.

16

2544-1022

RELAY;PREHEAT

desc: RELAIS DEMARREUR

1шт.

17

S0504453

BOLT M6X1.0X12

desc: BOULON A 6PANS

2шт.

18

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

19

544-00007

RELAY;STARTER

desc: RELAIS DEMARREUR

1шт.

20

S0504453

BOLT M6X1.0X12

desc: BOULON A 6PANS

2шт.

21

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

22

195-02193

BRACKET;RELAY

desc: RONDELLE ELASTIQUE

2шт.

23

2120-2235

BOLT;STUD M10X1.25X15

desc: GOUJON

1шт.

24

S0711853

BOLT M10X1.25X20

desc: BOULON A 6PANS

2шт.

25

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.
