Запчасти Doosan Daewoo REAR AXLE PLANET GEAR HYDRAULIC PARTS

1

808.01.017.01

PLUG

desc: BOUCHON

2шт.

3

176.06.001.06

AXLE CASE

desc: CORPS D'ESSIEU

2шт.

4

001.01.0668

SEAL

desc: JOINT

2шт.

5

176.06.013.01

CENTERING RING

desc: BAGUE

2шт.

6

176.06.006.01

WHEEL STUD

desc: GOUJON DE ROUE

24шт.

7

176.06.062.01

WHEEL HUB

desc: MOYEU DE ROUE

2шт.

8

006.11.1413

NUT

desc: ECROU

24шт.

9

016.02.1433

HEXAGON BOLT

desc: BOULON A 6 PANS

10шт.

10

176.06.012.02

HALF SHAFT

desc: DEMI-ARBRE

2шт.

11

002.07.1425

RING;SNAP

desc: CIRCLIP

12шт.

12

176.06.009.01

WASHER;FRICTION

desc: RONDELLE

12шт.

13

176.06.007.01

PIN

desc: GOUJON

6шт.

14

001.05.1423

O-RING

desc: JOINT TORIQUE

6шт.

15

176.06.701.02

PLANET GEAR CARRIER

desc: SUPPORT SATELLITES

2шт.

16

819.01.610.01

MAGNET PLUG

desc: BOUCHON

2шт.

17

016.05.0437

CYLINDER BOLT

desc: BOULON DE CULASSE

8шт.

18

171.06.010.02

WASHER;FRICTION

desc: RONDELLE

2шт.

19

014.02.1388

DOWEL

desc: GOUJON

6шт.

20

005.13.1428

NEEDLE BEARING

desc: ROULEMENT A AIGUILLES

6шт.

21

176.06.008.01

PLANET GEAR

desc: ENGRENAGE PLANETAIRE

6шт.

22

176.06.027.01

LOCKING PLATE

desc: PLAQUE

6шт.

23

016.02.1208

HEXAGON BOLT

desc: BOULON A 6 PANS

12шт.

24

176.06.016.01

LOCKING PLATE

desc: PLAQUE

2шт.

25

176.06.011.01

RING GEAR SUPPORT

desc: SUPPORT DE COURONNE DENTEE

2шт.

26

176.06.026.01

DOWEL

desc: GOUJON

10шт.

27

002.06.1117

RING;SNAP

desc: CIRCLIP

2шт.

28

176.06.010.03

RING GEAR

desc: COURONNE DENTEE

2шт.

29

001.05.1424

O-RING

desc: JOINT TORIQUE

2шт.

30

005.10.1427

TAPER ROLLER BEARING

desc: ROULEMENT A ROULEAUX CONIQUES

4шт.

31

001.25.1544

SEAL

desc: JOINT

2шт.
