Запчасти Doosan Daewoo FORWARD SHAFT HYDRAULIC PARTS

1

235763

BEARING

desc: PALIER

1шт.

2

234350

RING;SNAP

desc: BAGUE

1шт.

3

241313

RETAINER

desc: ARRETOIR

1шт.

4

247657

SPRING DISC

desc: DISQUE

1шт.

5

237442

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

6

234111

RING;SNAP

desc: BAGUE

1шт.

7

242650

PLATE;DRIVE

desc: PLAQUE

1шт.

8

237016

DISC;CLUTCH INNER

desc: DISQUE

12шт.

9

234109

DISC;CLUTCH OUTER

desc: DISQUE

12шт.

10

4204047

CLUTCH PISTON(WITH #11.12)

desc: PISTON DE CLUTCH

1шт.

11

237032

SEAL;CLUTCH PISTON-OUTER

SC: K

1шт.

12

234113

SEAL;CLUTCH PISTON-INNER

SC: K

1шт.

13

238034

RING;RETAINING

desc: BAGUE

1шт.

14

241819

BEARING;FORWARD SHAFT

desc: PALIER

1шт.

15

241037

SLEEVE

desc: MANCHE

1шт.

16

235764

RING;RETAINING

desc: BAGUE

1шт.

17

242651

RING;PISTON

SC: K

3шт.

18

237378

PISTON RING EXPANDER

SC: K

3шт.

19

242673

FORWARD SHAFT DRUM

desc: FORWARD CLUTCH SHAFT. DRUM & PLUG

1шт.

20

243876

FORWARD SHAFT GEAR

desc: ENGRENAGE

1шт.
