Запчасти Doosan Daewoo 3RD PIPING FRONT PARTS

-

400-00166

3rd PIPING

SERIAL: 1021

-2шт.

1

195-00520

BRACKET

desc: DISQUE

1шт.

2

S0511753

BOLT M10X1.5X18

desc: BOULON

2шт.

3

193-00081

PIPE;R.H

desc: CONDUITE

1шт.

4

193-00082

PIPE;L.H

desc: CONDUITE

1шт.

5

4116-1558

PLATE

desc: PLAQUE

2шт.

6

2180-1026D2

O-RING

desc: JOINT TORIQUE

2шт.

7

S2212261

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS

8шт.

8

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

8шт.

9

S5010613

WASHER;PLAIN M10

desc: RONDELLE

2шт.

10

S8040161

O-RING

desc: JOINT TORIQUE

2шт.

11

2181-2206D6

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

12

S8030121

O-RING

desc: JOINT TORIQUE

2шт.

13

4124-1652

CLAMP;PIPE

desc: ATTACHE DE TUBE

2шт.

14

S4012533

NUT M8X1.25

desc: ECROU

4шт.

15

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

16

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.
