Запчасти Doosan Daewoo OIL PUMP ENGINE PARTS

204
202
203
101
106
122
102
107
103
112
121
111
116
115
120
114
113
119
121
120
118
110
117
109
108

Артикул

Название

Примечание

Количество

101

65.05101-7021

OIL PUMP ASS'Y(NO.102Ў­118)

desc: RONDELLE DE BUTEE

1шт.

102

65.05103-0024

COVER;OIL PUMP

SC: D

1шт.

102

65.05102-0018

HOUSING;OIL PUMP

SC: D

1шт.

103

65.05104-6065

GEAR ASS'Y;OIL PUMP

desc: . COUVERCLE DE HUILE

1шт.

106

65.05105-0044

SHAFT;OIL PUMP

desc: . PIGNON

1шт.

107

65.05104-0177

GEAR;OIL PUMP

desc: . PIGNON

1шт.

108

65.05705-6016

STRAINER ASS'Y

desc: . ARBRE

1шт.

109

06.01013-9117

BOLT M8X65

desc: . ENSEMBLE POMPE A HUILE

4шт.

110

06.16731-2107

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

4шт.

111

65.05103-0051

COVER;OIL PUMP

SC: D

1шт.

112

65.91710-0012

RING;STOPPER

desc: . BOULON A 6 PANS

1шт.

113

06.22070-0913

PIN;SPLIT 4Ўї30

desc: . RONDELLE ELASTIQUE

1шт.

114

65.91305-0007

SEAT;SPRING

desc: . COUVERCLE

1шт.

115

65.97601-0090

SPRING;COMPRESSION

desc: . BAGUE

1шт.

116

06.31641-0222

BALL;STEEL 15/32

desc: . GOUJON

1шт.

117

06.01913-3113

BOLT ASS'Y M8X20

desc: . RESSORT

2шт.

118

65.96601-0058

GASKET

desc: . RESSORT

1шт.

119

65.05701-5636

OIL PIPE ASS'Y

desc: BILLE

1шт.

120

06.01923-3120

BOLT ASS'Y M8X45

desc: BOULON A 6 PANS

4шт.

121

65.05903A0002

GASKET

desc: JOINT

2шт.

122

06.01944-3215

BOLT ASS'Y M10X1.25X25

desc: CONDUITE

2шт.

202

65.05201-0065

GEAR;OIL PUMP DRIVE

desc: BOULON A 6 PANS

1шт.

203

65.05207-0006

COUPLING;SLEEVE

desc: JOINT

1шт.

204

65.05202-0001A

BUSH;DRIVE GEAR

desc: BOULON A 6 PANS

1шт.

Выбрано товаров: 24
