Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

101

65.03101-6049

CYLINDER HEAD ASS'Y

desc: PARE-POUSSIERES

1шт.

102

65.03101-1043

HEAD;CYLINDER

SC: D

1шт.

104

65.03201-1013

GUIDE;VALVE

SC: D

12шт.

105

65.03203-1020

SEAT;EXHAUST VALVE

SC: D

6шт.

106

65.03203-1019

SEAT;INLET VALVE

SC: D

6шт.

107

65.90302-0015

PLUG;CORE(NEAR FACE)

desc: . SIEGE

1шт.

108

65.90302-0016

PLUG;CORE(EXHAUST MAIN)

desc: . BOUCHON

3шт.

109

65.90302-0019B

PLUG;CORE

desc: . BOUCHON

11шт.

110

06.15090-2313

PLUG;CORE

desc: . COUPELLE

3шт.

111

06.15090-2305

PLUG;CORE

desc: . BOUCHON

6шт.

112

65.90302-0011

PLUG;DRILLED PASS

desc: . BOUCHON

6шт.

113

65.90302-0017

PLUG;WATER JET CORE

desc: BOUCHON

6шт.

114

65.91710-0004

RING;STOPPER

desc: GOUJON

2шт.

115

65.90020-0294

BOLT;CYLINDER HEAD

desc: BOULON DE CULASSE

18шт.

116

65.90020-0295

BOLT;CYLINDER HEAD

desc: BOULON DE CULASSE

6шт.

117

65.90020-0296

BOLT;CYLINDER HEAD

desc: BOULON DE CULASSE

2шт.

119

06.06225-0706

BOLT;STUD

desc: GOUJON

3шт.

120

06.06125-8717

BOLT;STUD

desc: GOUJON

7шт.

121

65.90201-0016

STUD BOLT M8X97

desc: GOUJON

1шт.

122

06.06125-8711

STUD BOLT M8X45

desc: GOUJON

2шт.

123

06.06125-8709

STUD BOLT M8X35

desc: GOUJON

2шт.

124

65.19202-5005

HOOK;LIFTING

desc: GOUJON

1шт.

125

65.03901-0055

GASKET;CYLINDER HEAD

desc: CROCHET

1шт.

127

65.26810-0007

CONNECTOR

desc: JOINT

1шт.

128

06.16731-2110

WASHER;SPRING

desc: RACCORD

1шт.

129

06.01733-4409

BOLT;HEX M14X1.5X25

desc: RONDELLE ELASTIQUE

1шт.

130

06.16731-2108

WASHER;SPRING

desc: BOULON A 6 PANS

1шт.

131

06.01733-4208

BOLT M10X1.25X22

desc: RONDELLE

1шт.

132

65.26803-7014B

PLUG;GLOW

desc: BOULON A 6 PANS

6шт.

133

65.19202-0005

HOOK;LIFTING

desc: PRISE DE LUEUR

1шт.

134

06.01943-3213

BOLT ASS'Y M10X1.25X20

desc: CROCHET

2шт.

139

65.04902-0011A

SEAL;VALVE STEM

desc: BOULON A 6 PANS

12шт.

201

65.03401-6043

CYLINDER HEAD COVER ASS'Y

SERIAL: 000720

1шт.

201

65.03401-6043B

CYLINDER HEAD COVER ASS'Y

SERIAL: 000721

1шт.

206

65.90501-0007

NUT;CYLINDER HEAD COVER

SERIAL: 991029

4шт.

206

65.90501-0028

NUT;CYLINDER HEAD COVER

SERIAL: 991030

4шт.

207

65.90701-0018

WASHER;PLATE

SERIAL: 991029

4шт.

207

65.90701-0202

WASHER;PLATE

SERIAL: 991030

4шт.

208

65.03905-0002

GASKET;CYL. HEAD COVER

SERIAL: 991029

4шт.

208

REP_PNO: 65.90701-0202

-1шт.

208

REP_PNO: 65.90501-0028

-1шт.

208

65.03905-0023

GASKET;CYL. HEAD COVER

SERIAL: 991030

4шт.

210

65.03903-0001

PACKING(FOR COVER)

desc: RONDELLE

1шт.

211

65.03435-0001

COVER (FOR C/H C)

desc: RONDELLE

1шт.

212

06.04190-8808

BOLT M5X16

desc: BOITE

6шт.

213

06.16731-2104

WASHER;SPRING

desc: VIS

6шт.

217

06.67020-0102

CLAMP

desc: COLLIER

1шт.

218

65.96301-0325

HOSE;RUBBER

desc: RONDELLE

1шт.

219

65.97401-0144

CLIP;HOSE FOR OIL COOLER

desc: TUYAU FLEXIBLE

2шт.

220

65.01810-5005

CAP;OIL FILLER

SERIAL: 951212

1шт.

220

65.01810-5007

CAP;OIL FILLER

SERIAL: 951213

1шт.

226

65.03905-0002

GASKET;CYLINDER HEAD COVER

SERIAL: 991029

1шт.

226

65.03905-0002B

GASKET;CYLINDER HEAD COVER

SERIAL: 991030

1шт.
