Запчасти Doosan Daewoo AIRCONDITIONER(2) BODY PARTS

-

4920-1090

AIR CONDITIONER(2)

SC: D

-2шт.

20

4185-1731

HOSE;COMPRESSOR

desc: TUYAU FLEXIBLE

1шт.

21

2180-1219

WASHER;SEAL

desc: RONDELLE D'ETANCHEITE

2шт.

22

S2212361

BOLT;SOCKET M10X1.5X35

desc: BOULON A 6 PANS CREUX M10X1.5X35

1шт.

23

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

1шт.

24

S5020603

WASHER;PLAIN M10

desc: RONDELLE PLATE

1шт.

25

2185-1369D15

HOSE;LIQUID(1) 350L

desc: TUYAU FLEXIBLE

1шт.

26

2185-1369D9

HOSE;LIQUID(2) 2000L

desc: TUYAU FLEXIBLE LIQUIDE

1шт.

27

2520-6003A

CONDENSER

desc: ENSEMBLE COMPRESSEUR

1шт.

28

S0553653

BOLT M6X1.0X50

desc: BOULON

4шт.

29

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

4шт.

30

S5010313

WASHER;PLAIN M6

desc: RONDELLE

4шт.

31

S4012333

NUT M6X1.0

desc: ECROU M6X1.0

4шт.

32

4195-4871A

BRACKET;CONDENSER(R.H.)

desc: SUPPORT

1шт.

33

4195-4872A

BRACKET;CONDENSER(L.H.)

desc: SUPPORT

1шт.

34

S0558553

BOLT M10X1.5X50

desc: BOULON A 6 PANS

4шт.

35

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

4шт.

36

2114-1058D1

WASHER

desc: RONDELLE

4шт.

37

2512-1077

RUBBER;CUSHION

desc: CAOUTCHOUC

8шт.

38

4621-2922

COVER;BAFFLE

desc: COUVERCLE

2шт.

39

2920-6102

FAN;CONDENSER

desc: VENTILATEUR

1шт.

40

S4012333

NUT M6X1.0

desc: ECROU M6X1.0

3шт.

41

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

3шт.

42

S5010313

WASHER;PLAIN M6

desc: RONDELLE

5шт.

43

2204-6032

RECEIVER DRIER

desc: RESERVOIR DESSICATEUR

1шт.

44

2514-6001

HOLDER;RECEIVER DRIER

desc: POSSESSEUR

1шт.

45

S0504453

BOLT M6X1.0X12

desc: BOULON A 6 PANS

2шт.

46

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

2шт.

47

4920-1049E

A.H.U ASS'Y

desc: ENSEMBLE DE A.H.U

1шт.

47A

2920-9031C

UNIT;AIR HANDLING

desc: . UNITE

1шт.

48

S0508653

BOLT M8X1.25X16

desc: BOULON A 6 PANS

4шт.

49

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE M8

4шт.

50

2114-1058D29

WASHER

desc: RONDELLE

4шт.

51

2124-1509D6

CLIP d42/M8

desc: ATTACHE

1шт.

52

2124-1509D3

CLIP d24/M8

desc: ATTACHE

1шт.

53

2121-1305

NUT M8X1.25

desc: ECROU

2шт.

54

2124-1622D3

CLIP;BAND 280L

desc: ATTACHE

10шт.
