Запчасти Doosan Daewoo ENGINE CONTROL BODY PARTS

-

4201-1089

ENGINE CONTROL

SC: D

-2шт.

1

4134-9401

PEDAL ASS'Y

desc: PEDALE ASS'Y

1шт.

2

S0504853

BOLT M6X1X20

desc: BOULON A 6 PANS

3шт.

3

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE M6

6шт.

4

S5010313

WASHER;PLAIN M6

desc: RONDELLE

4шт.

5

4139-6058D7

CABLE CONTROL

desc: CABLE DE COMMANDE

1шт.

6

S5010513

WASHER;PLAIN

desc: RONDELLE M8

2шт.

7

4195-3804A

BRACKET

desc: SUPPORT

1шт.

8

S0711953

BOLT M10X1.25X22

desc: BOULON A 6 PANS

2шт.

9

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

2шт.

10

2195-3805

BRACKET

desc: SUPPORT

1шт.

11

S0504453

BOLT M6X1X12

desc: BOULON A 6 PANS

3шт.

12

2138-9006B

JOINT;BALL

desc: JOINT SPHERIQUE

1шт.

13

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE M5

2шт.

14

S4012233

NUT M5X0.8

desc: ECROU M5X0.8

1шт.

15

S0508853

BOLT M8X1.25X20

desc: BOULON A 6 PANS

2шт.

16

2523-9016

MOTOR;STOP

desc: MOTEUR

1шт.

17

S0508453

BOLT M8X1.25X12

desc: BOULON M8X1.25X12

1шт.

18

S0556253

BOLT M8X1.25X45

desc: BOULON A 6 PANS

1шт.
