Запчасти Doosan Daewoo COOLER PIPING BODY PARTS

-

4202-1023

COOLING PIPING

SC: D

-2шт.

1

4202-9071A

RADIATOR

desc: RADIATEUR

1шт.

1A

4623-1180C

FAN;GUARD

desc: . BARRE DE PROTECTION

1шт.

1B

4623-4011B

FAN;GUARD

desc: . BARRE DE PROTECTION

1шт.

2

4197-2237

BRACKET(R.H.)

desc: SUPPORT

1шт.

3

4195-2243

BRACKET(L.H.)

desc: SUPPORT

1шт.

4

4145-1283

STAY

desc: ENTRETOISE

2шт.

6

4181-2478

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

7

2180-1026D12

O-RING

desc: JOINT TORIQUE

2шт.

8

4181-4277A

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

9

4181-4276A

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

10

4181-2306B

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

11

2181-4133D5

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

12

S8030121

O-RING

desc: JOINT TORIQUE

3шт.

13

S8000241

O-RING PF3/4

desc: JOINT TORIQUE

1шт.

14

2184-1061D144

HOSE

desc: TUYAU FLEXIBLE

1шт.

15

2184-1061D194

HOSE

desc: TUYAU FLEXIBLE

1шт.

16

2184-1197D40

HOSE

desc: TUYAU FLEXIBLE

1шт.

17

2184-1219D1

HOSE

desc: TUYAU FLEXIBLE

1шт.

18

4161-2379A

PLATE;RUBBER

desc: PLAQUE

2шт.

19

S0560453

BOLT M12X1.75X35

desc: BOULON A 6 PANS

4шт.

20

S0512153

BOLT M10X1.5X28

desc: BOULON A 6 PANS

9шт.

21

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE M10

9шт.

22

4181-2580

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

24

S0515253

BOLT M12X1.75X30

desc: BOULON A 6 PANS

4шт.

25

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE M12

8шт.

26

2114-1058D46

WASHER;PLAIN

desc: RONDELLE

6шт.

27

2124-1024D10

CLAMP

desc: COLLIER

5шт.

28

2124-1024D12

CLAMP

desc: COLLIER

1шт.

30

4185-4060

HOSE

desc: TUYAU FLEXIBLE

1шт.

31

4185-1727A

HOSE

desc: TUYAU FLEXIBLE

1шт.

32

4185-4062

HOSE

desc: TUYAU FLEXIBLE

1шт.

33

2182-1323

PIPE

desc: TUYAU D'EAU

1шт.

34

2114-1058D45

WASHER;PLAIN

desc: RONDELLE

4шт.

35

161-00218

SPONGE

SERIAL: 1044

1шт.
