Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

101

65.03101-6049

CYLINDER HEAD ASS'Y

SERIAL: 020919

1шт.

101

65.03101-6071A

CYLINDER HEAD ASS'Y

SERIAL: 040924

1шт.

101

65.03101-6071B

CYLINDER HEAD ASS'Y

SERIAL: 040925

1шт.

102

65.03101-1043

HEAD;CYLINDER

SERIAL: 020919

1шт.

102

65.03101-1043C

HEAD;CYLINDER

SERIAL: 020920

1шт.

104

65.03201-1013

GUIDE;VALVE

SERIAL: 040924

12шт.

104

65.03201-1013A

GUIDE;VALVE

SERIAL: 040925

12шт.

105

65.03203-1020

SEAT;EXHAUST VALVE

SERIAL: 020919

6шт.

105

65.03203-1054

SEAT;EXHAUST VALVE

SERIAL: 020920

6шт.

106

65.03203-1019

SEAT;INLET VALVE

SERIAL: 020919

6шт.

106

65.03203-1053

SEAT;INLET VALVE

SERIAL: 020920

6шт.

107

65.90302-0015

PLUG;CORE(NEAR FACE)

desc: . BOUCHON

1шт.

108

65.90302-0016

PLUG;CORE(EXHAUST MAIN)

SERIAL: 020919

3шт.

108

65.90302-0030

PLUG;CORE(EXHAUST MAIN)

SERIAL: 020920

6шт.

109

65.90302-0019B

PLUG;CORE

desc: . COUPELLE

11шт.

110

06.15090-2313

PLUG;CORE

SERIAL: 020919

3шт.

110

65.90302-0045

PLUG;CORE

SERIAL: 020920

3шт.

111

06.15090-2305

PLUG;CORE

SERIAL: 020919

6шт.

111

65.90302-0027

PLUG;CORE

SERIAL: 020920

6шт.

112

65.90302-0011

PLUG;DRILLED PASS

desc: . BOUCHON

6шт.

113

65.90302-0017

PLUG;WATER JET CORE

desc: BOUCHON

6шт.

115

06.06125-8711

BOLT;STUD M8X45

desc: GOUJON

2шт.

116

06.06225-0706

BOLT;STUD INTAKE STAKE

desc: GOUJON

3шт.

117

06.06125-8717

BOLT;STUD

desc: GOUJON

7шт.

118

06.06125-8709

BOLT;STUD M8X35

desc: GOUJON

2шт.

119

65.91710-0004

RING;STOPPER

desc: BAGUE

2шт.

120

65.90020-0294

BOLT;CYLINDER HEAD

SERIAL: 060508

18шт.

120

65.90021-0002

BOLT;CYLINDER HEAD

SERIAL: 060509

18шт.

121

65.90020-0295

BOLT;CYLINDER HEAD

SERIAL: 060508

6шт.

121

65.90021-0003

BOLT;CYLINDER HEAD

SERIAL: 060509

6шт.

122

65.90020-0296

BOLT;CYLINDER HEAD

SERIAL: 060508

2шт.

122

65.90021-0004

BOLT;CYLINDER HEAD

SERIAL: 060509

2шт.

123

65.90201-0016

BOLT;STUD M8X97

desc: GOUJON

1шт.

124

65.19202-5005

HOOK;LIFTING

desc: CROCHET

1шт.

125

65.03901-0055

GASKET;CYLINDER HEAD

desc: JOINT

1шт.

127

65.26810-0007

CONNECTOR

desc: RACCORD

1шт.

128

06.16731-2110

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

129

06.01733-4409

BOLT;HEX M14X1.5X25

desc: BOULON A 6 PANS

1шт.

130

06.16731-2108

WASHER;SPRING

desc: RONDELLE

1шт.

131

06.01733-4208

BOLT M10X1.25X22

desc: BOULON A 6 PANS

1шт.

132

65.26803-7014B

PLUG;GLOW

SERIAL: 040115

6шт.

132

65.26803-7014C

PLUG;GLOW

SERIAL: 060421

6шт.

132

65.26803-7014D

PLUG;GLOW

SERIAL: 060422

6шт.

133

65.19202-0005

HOOK;LIFTING

desc: CROCHET

1шт.

134

06.01943-3213

BOLT ASS'Y M10X1.25X20

desc: BOULON A 6 PANS

2шт.
