Запчасти Doosan Daewoo ELECTRIC PARTS(7)-RELATED PARTS (TIER-II) BODY PARTS

-

500-00184

ELECTRIC PARTS

SC: D

-2шт.

31

2516-1124

BUZZER;BACK UP

desc: VIBREUR ARRIERE

1шт.

32

S0508653

BOLT M8X1.25X16

desc: BOULON A 6PANS

2шт.

33

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

34

S5010513

WASHER;PLAIN M8

desc: RONDELLE M8

2шт.

38

2534-1159C

LAMP;REAR COMBI (L.H)

SERIAL: 1001-1133

1шт.

38A

2534-6028

CASE;LAMP

desc: . CARTER

1шт.

38B

S864221H

BULB(T/S STOP)24V 21W

desc: . LAMPE

2шт.

38C

S863210H

BULB(POSITION)24V 10W

desc: . LAMPE

1шт.

38D

S863212H

BULB(STOP BACK UP)24V 12W

desc: . LAMPE

2шт.

39

2534-1158C

LAMP;REAR COMBI (R.H)

SERIAL: 1001-1133

1шт.

39A

2534-6029

CASE;LAMP

desc: . CARTER

1шт.

39B

S864221H

BULB(T/S STOP)24V 21W

desc: . LAMPE

2шт.

39C

S863210H

BULB(POSITION)24V 10W

desc: . LAMPE

1шт.

39D

S863212H

BULB(STOP BACK UP) 24V 12W

desc: . LAMPE

2шт.

40

2534-1139A

LAMP;LICENCE 24V 5W

desc: LAMPE

1шт.

40A

2534-6019

CASE;LAMP

desc: . CARTER

1шт.

40B

2515-1021D5

BULB 24V 5W

desc: . LAMPE

1шт.

41

547-00019A

SENSOR;FUEL

desc: SENDER

1шт.

42

S0502953

BOLT M5X0.8X12

desc: BOULON A 6PANS

5шт.

43

S5100203

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

5шт.
