Запчасти Doosan Daewoo RESERVE & 2ND SHAFT HYDRAULIC PARTS

1

249779

RING;PISTON

SC: K

3шт.

2

246238

RING;RETAINING

desc: BAGUE

1шт.

3

230889

RING;SNAP

desc: BAGUE

1шт.

4

241606

BEARING;2nd SHAFT

desc: PALIER

1шт.

5

802152

RING;RETAINING

desc: BAGUE

1шт.

6

241278

DRIVEN GEAR ASS'Y

desc: EMBRAYER

1шт.

7

234350

RING;SNAP

desc: BAGUE

1шт.

8

241313

RETAINER;SPRING

desc: ARRETOIR

11шт.

9

247657

DISC SPRING

desc: RESSORT DE DISQUE

1шт.

10

237442

SPACER

desc: BAGUE D'ECARTEMENT

1шт.

11

234111

RING;SNAP

desc: BAGUE

1шт.

12

242650

PLATE;BACKING

desc: PLAQUE

1шт.

13

237016

DISC;CLUTCH INNER

desc: DISQUE

6шт.

14

234109

DISC;CLUTCH OUTER

desc: DISQUE

5шт.

15

4204498

CLUTCH PISTON(WITH #16.17)

desc: PISTON DE CLUTCH

1шт.

16

237032

SEAL;CLUTCH PISTON OUTER

SC: K

1шт.

17

234113

SEAL;CLUTCH PISTON INNER

SC: K

1шт.

18

246235

2nd SHAFT DRUM

desc: REVERSE & 2ND CLUTCH DRUM & PLUG

1шт.

19

234113

SEAL;CLUTCH PISTON INNER

SC: K

1шт.

20

237032

SEAL;CLUTCH PISTON OUTER

SC: K

1шт.

21

4204047

CLUTCH PISTON(WITH #19.20)

desc: PISTON DE CLUTCH

1шт.

22

234109

DISC;CLUTCH OUTER

desc: DISQUE

12шт.

23

237016

DISC;CLUTCH INNER

desc: DISQUE

12шт.

24

242650

PLATE;BACKING

desc: PLAQUE

1шт.

25

234111

RING;SNAP

desc: BAGUE

1шт.

26

235960

SPRING;PISTON RETURN

desc: RESSORT

1шт.

27

235959

RETAINER;SPRING

desc: ARRETOIR

1шт.

28

234350

RING;SNAP

desc: BAGUE

1шт.

29

233065

BEARING

desc: PALIER

1шт.

30

241603

RING;LOCATING

desc: BAGUE

1шт.

31

241313

RING;RETAINER

desc: ARRETOIR

1шт.

32

234350

RING;RETAINING

desc: BAGUE

1шт.

34

4203200

2ND CLUTCH DISC HUB

desc: HUB DE DISQUE

1шт.

35

242961

CLUTCH GEAR(WITH #36)

desc: REVERSE CLUTCH GEAR & HUB

1шт.

36

240617

RING;RETAINING

desc: BAGUE

1шт.
