Запчасти Doosan Daewoo OVERLOAD & ANTI-CAVITATION VALVE HYDRAULIC PARTS

1

21283006

OVER LOAD & ANTI. CAVI. VALVE

desc: DECHARGE

1шт.

1A

06815002

SEAL;O-RING

desc: JOINT

1шт.

1B

12049001

RING;BACK UP

desc: BAGUE

1шт.

1C

20530001

SPRING

desc: RESSORT

1шт.

1D

07495001

SEAL;O-RING

desc: JOINT

1шт.

1E

11046001

PISTON;ANTICAVITATION

desc: PISTON

1шт.

1F

06814002

SEAL;O-RING

desc: JOINT

2шт.

1G

09021019

RING;BACK UP

desc: BAGUE

1шт.

1H

11060001

BODY

desc: CARROSSERIE

1шт.

1I

06884001

SEAL;O-RING

desc: JOINT

1шт.

1J

10035001

WASHER

desc: RONDELLE

1шт.

1K

09302006

NUT

desc: ECROU

1шт.

1L

08956001

SCREW

desc: VIS

1шт.

1M

10034001

COVER;TAMPER PROOF

desc: COUVERCLE

1шт.

1N

10059001

SPRING

desc: RESSORT

1шт.

1O

08475001

POPPET;RELIEF

desc: SOUPAPE SOULEVANTE

1шт.

1P

02708001

SEAL;O-RING

desc: JOINT

1шт.

1Q

08994001

BODY

desc: CARROSSERIE

1шт.

1R

02709001

SEAL;O-RING

desc: JOINT

1шт.

1S

08732001

RING;RETAINING

desc: BAGUE

1шт.

1T

21703001

POPPET

desc: SOUPAPE SOULEVANTE

1шт.

1U

20902001

RING;BACK UP

desc: BAGUE

1шт.

1V

20904001

RING;BACK UP

desc: BAGUE

1шт.

2

21497002

ANTI.-CAVI. VALVE

desc: ANTICAVITATION

1шт.

2A

06815002

SEAL;O-RING

desc: JOINT

1шт.

2B

12049001

RING;BACK UP

desc: BAGUE

1шт.

2C

20530001

SPRING

desc: RESSORT

1шт.

2D

07495001

SEAL;O-RING

desc: JOINT

1шт.

2E

11046001

PISTON;ANTICAVITATION

desc: PISTON

1шт.

2F

06814002

SEAL;O-RING

desc: JOINT

2шт.

2G

09021019

RING;BACK UP

desc: BAGUE

1шт.

2H

08732001

RING;RETAINING

desc: BAGUE

1шт.

2I

11334001

PLUG

desc: BOUCHON

1шт.

2J

21703001

POPPET

desc: SOUPAPE SOULEVANTE

1шт.

2K

20902001

RING;BACK UP

desc: BAGUE

1шт.

2L

02708001

SEAL;O-RING

desc: JOINT

1шт.

2M

08994001

BODY

desc: CARROSSERIE

1шт.

2N

02709001

SEAL;O-RING

desc: JOINT

1шт.

2O

20904001

RING;BACK UP

desc: BAGUE

1шт.
