Запчасти Doosan Daewoo CONTROL VALVE MOUNTING HYDRAULIC PARTS

1

1C688

SCREW;VALVE MOUNTING

desc: VIS

4шт.

2

4E-06

WASHER;LOCK

desc: RONDELLE

4шт.

3

60K30014

O-RING

desc: JOINT TORIQUE

1шт.

4

247666

GASKET;MODULATOR VALVE

desc: JOINT

1шт.

5

248044

CONTROL VALVE

desc: VANNE DE COMMANDE

1шт.

6

4E-06

WASHER;LOCK

desc: RONDELLE

5шт.

7

241123

SCREW;VALVE MOUNTING

desc: VIS

3шт.

22

4202506

MODULATOR VALVE

desc: VANNE

1шт.

23

248006

GASKET

desc: JOINT

1шт.
