Запчасти Doosan Daewoo CRANK SHAFT ENGINE PARTS

101

65.02101-6018

CRANK SHAFT ASS'Y

SERIAL: 000715

1шт.

101

65.02101-6018A

CRANK SHAFT ASS'Y

SERIAL: 000716

1шт.

103

65.02101-0045A

SHAFT;CRANK

desc: . VILEBREGUIN

1шт.

105

06.22022-3210

PIN;PARALLEL

SERIAL: 000715

1шт.

105

06.22022-3212

PIN;PARALLEL(ЁЄ12x20)

SERIAL: 000716

1шт.

104

65.02115-0013

GEAR;CRANK SHAFT

desc: PIGNON DE VILEBREQUIN

1шт.

106

65.93020-0015

BUSH;TAPER

desc: PIGNON DE VILEBREQUIN

1шт.

108

65.02120-0002

RING;OIL THROWER

desc: COUSSINET

1шт.

109

65.90501-0006

NUT

desc: BAGUE

1шт.

110

65.91501-0006

KEY;SLIDING

desc: ECROU

1шт.

201

65.02301-5055

FLYWHEEL ASS'Y

desc: KEY

1шт.

202

65.02310-0006

GEAR;STARTING RING

desc: . VOLANT

1шт.

204

65.02301-0203

FLY WHEEL

desc: . ENGRENAGE

1шт.

207

06.01494-4506

BOLT M16Ўї1.5Ўї35

desc: VOLANT

6шт.

208

06.16731-2111

WASHER;SPRING

desc: BOULON A 6 PANS

6шт.

301

65.02401-6205B

CONNECTING ROD ASS'Y

SERIAL: 00525

6шт.

301

65.02401-6205D

CONNECTING ROD ASS'Y

SERIAL: 000526

6шт.

305

65.02411-0006

BOLT

SERIAL: 970909

2шт.

305

65.02411-0006A

BOLT

SERIAL: 970910

2шт.

308

65.02401-0163C

ROD;CONNECTING

SC: D

1шт.

309

65.02405-0163B

BUSH

SC: D

1шт.

306

65.02410-6083

METAL;CON-ROD STD

desc: AMPOULE

6шт.

401

65.02501-0561

PISTON(ALTV.)

desc: PIISTON

6шт.

402

65.02501-0562

PISTON;A GRADE

desc: PIISTON

6шт.

403

65.02501-0563

PISTON;B GRADE

desc: PIISTON

6шт.

404

65.02503-0099

RING;TOP

desc: PIISTON

6шт.

405

65.02503-0116

RING;SECOND

desc: SEGMENT COUP DE FEU

6шт.

406

65.02503-0114

RING;OIL

desc: SEGMENT DE COMPRESSION

6шт.

412

65.02502-0082A

PIN;PISTON

desc: AXE DE PISTON

6шт.

413

65.90815-0007

RING;RETAINING

desc: BAGUE

12шт.

501

65.02601-5019

PULLEY;DAMPER

desc: BAGUE

1шт.

503

65.02122-0001

COVER;DUST

desc: POULIE

1шт.
